Nuvo SATCO TP231 Instructions

Pendant Track Adapter Instructions (TP231, TP232, TP233)
Recommended for use on pendants with SVT Cable. Adapter will support up to 10lbs.
Tools needed for install: Small blade flathead screwdriver, Phillips head screwdriver
In this kit you will have the following: (1) Track Adapter, (3) Wire Nuts, (1) Strain Relief (see Fig. 1)
Step 1: Unscrew the 2 phillips head screws at the bottom of the Track Adapter and remove the bottom
cover (see Fig. 2)
Step 2: Cut the SVT cable to the desired length and thread it through the bottom cover (see Fig. 3)
Step 3: Loop the SVT Cable through the strain relief (see Fig. 4)
Step 4: Using the wire nuts provided connect your pendant wires to the track adapter wires (hot to hot,
neutral to neutral and ground to ground) and carefully push the wire nuts down into the body of the
track adapter (see Fig. 5)
Step 5: Place the bottom cover back into position being careful not to trap any wires and secure using
the 2 screws that were removed in Step 1. Then using a flat head screw driver tighten the tension screw
to secure the cable in to place (see Fig. 6)
Step 6: Make sure the switch on the Track Adapter is in the "OFF" position and install the pendant on to
the track. Once it is installed properly turn the switch on.
Fig. 1 Fig. 2 Fig. 3
Fig. 4 Fig. 5 Fig. 6
