AWSS
Wind and Sun Sensor Installation Manual
T
Wind-sun sensor specification
Technical
s u p p o r t
DM45R，DM45RD
AWRC
~110V/60Hz AWSS
T
Button specification
Wind Set Button
Technical
s u p p o r t
Sun Setting Button
Up UP Button
Setting Button
P2
LED
T
Mounting Tips
Technical
s u p p o r t
Live
Neutral
AWSS
Wiring
Stable performance
Frequency：433.92MHz
Range of validity：outdoor 200 meters
2 screws fixed
AC power：110V/60Hz
Safety code (50 million times without repeat,high security)
Can set four differentwind scales and four different sunlight ranks
When the wind power is more than the setting value for 3 seconds,
the sensor will automatically close awning. After closed, the sensor
will not the wind in three minute.
When the light level is more than the setting value for 2 minutes,
the sensor will automatically unfolds awning.
When the light level does not reach the setting value for 15 minutes,
the sensor will automatically close awning.
Note:Make sure to confirm that sensor has been programmed with
the supporting receiver before use.
If wants to change the installationsite, it needs open
the power junction box, looses the fixed screw.
After adjusting the installationsite,tighten the screws up.
