Classic Hercules 127006-1100 Assembly Instructions

fits all sizes
PARTS
1- Right Side Frame
1- Left Side Frame
2- Extender Bars
1- Center Bracket
7- Carpet Rollers
1- Wrench
3- Bolts
3- Washers
3- Nuts
QUEEN FULL
4
STEP 4: Place support
bar in center and align
with holes on top.
8
FOR VIDEO INSTRUCTIONS PLEASE GO TO
ASSEMBLY INSTRUCTIONS
1
STEP 1: Swing out cross
arms on both side pieces
to 90 degrees.
NOTE:
TWIN
of key holes cor-
respond to bed
frame size. An
Extender bar is
included for King
and Cal King
5
STEP 5: Place bolt into hole on
top center of bed frame.
WWW.HERCULESBEDFRAME.COM
BED FRAME
EXTENDER
CAL KING
EXTENDER
2
Each set
3
6
STEP 6: Secure washer and
nut with enclosed wrench. Re-
peat steps 6-7 on other side.
STEP 8:
Bed frame is as-
semled and ready for use.
STEP 9:
Headboard
bracket can be attached to
headboard if necessary.
KING AND CAL
KING
KING EXTENDER:
Line the rivets on
the extender with
the key holes on the
BED FRAME
frame and lock into
place.
STEP 2: Place rivets
of the cross arms into
apporpiate key holes.
STEP 3:
Slide rivets
to lock in place. Re-
peat step 2 and 3 on
other side.
7
STEP 7: Slide carpet
rollers into bed frame
legs.
9
