Rapesco 1321 Manual

Model: Adjustable 6-Hole Organiser Punch - Settings & Compatibility
A5 Organisers
NOTE: The cutters nearest the paper guide/ ruler
are the only cutters required for A5 punching.
Agenda & A6 Organisers
E
Planner & Timer
21 Organisers
NOTE: The cutters nearest the paper guide/ ruler are the only cutters required for Planner & Timer 21 punching.
70mm / 2 3 ⁄ "
4
Make sure that the
punching cutters lines are
set with the lines for A5 organiser size.
Pull out the paper guide/ruler as far out as
possible until the A5 mark clicks into place.
Position your A5 paper so that one edge lines
up with the end of the paper guide/ruler.
Punch the first set of 3-holes, flip the paper
over and repeat the same process for the
second set of holes.
The punched sheet will now fit an A5 organiser.
38mm / 1 1 ⁄ "
2
Position the punching
cutters A so the cutter
lines are set with the lines for Agenda & A6
Use the centre mark E on the punch top for the
centre positioning on your paper/refills.
Punch your paper for your refill to fit into an
Agenda/ A6 organiser.
50mm / 2 "
Push the punching cutters
A apart / both to the outer
edge of the punch, so the cutter lines are set
with the lines for Planner & Timer 21.
Pull out the paper guide/ruler until the Timer
21 mark clicks into place.
Position your paper so that one edge lines up
with the end of the paper guide/ruler. Punch the
first set of 3-holes, flip the paper over and repeat
the same process for the second set of holes.
(Codes: 1321, 1322, 1324, 1342 & 1344)
Pocket & Timer
14 Organisers
Personal, Compact, Slimline
& Timer 17 Organisers
Mini Organisers
E
NOTE: On first use the punching cutters may be stiff to move, but this will ease with use. Also,
when aligning for A5, Planner, Timer 21 & Mini, the centre mark E on the punch top is not applicable.
Push the punching
cutters A together so
the cutter lines are set with the lines for
Pocket & Timer 14.
Use the centre mark E on the front of the
punch top for the centre positioning on your
paper refill, as well as positioning the paper
so that the top edge lines up with the line
marking " Pocket" on the front of
the base.
50mm / 2"
Push the punching
cutters A apart / both
to the outer edge of the punch, so the cutter
lines are set with the lines for Personal,
Compact, Slimline & Timer 17.
Use the centre mark E on the punch top for
the centre positioning on your paper/refills.
Also pull out the paper guide/ ruler until the
PERSONAL mark clicks into place.
Position your paper so the one edge lines up
with the end of the paper guide/ruler.
The punched sheet will now fit a Personal,
Compact, Slimline & Timer 17 organiser.
Make sure that the punching cutter lines are
set for Mini organiser size.
Position your Mini organiser paper refill so that
top edge lines up with the line marking "
Mini" on the front of the base.
The punched sheet will now fit a
Mini organiser.
