- Page 1 U S E R M A N U A L Analog Audio Extender over single Cat5e/6 cable Up to 450meter...
-
Page 2: Dear Customer
Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of HDMI converters, switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient, more comfortable, more productive and more cost-efficient. -
Page 3: Specifications
Specifications: Operating Temperature Rang ............0~40℃(+32~+104°F) Operating Humidity Range ..........5~90%RH(Not Condensation) Data transfer speed ....................... 6.9Mbps Sampling rate ...................... 44.1Khz,48KHz Audio format ......................... L/PCM2.0 Power consumption ................. 1.5watts(Maximum) Storage Temperature ............... -20°C ~ 60°C / -4°F ~ 140°F Dimension (L x W x H) ..................68*58*24(mm) Net Weight ................ -
Page 4: Panel Description
Panel Description: Transmitter panel A. DC12 V: Connect to the 12V DC power supply into the unit and plug the adaptor to an AC wall outlet. B. RJ45 OUT: Connect the RJ45 output of the transmitter to the RJ45 input of the receiver (Warning:CAT5E/6 cable must be a IEEE 568B standard connection method or the product will be damaged! ) C. - Page 5 Receiver Panel A. DC12 V: Connect to the 12V DC power supply into the unit and plug the adaptor to an AC wall outlet. B. RJ45 IN: Connect the RJ45 output of the transmitter to the RJ45 input of the receiver (Warning:CAT5E/6 cable must be a IEEE 568B standard connection method or the product will be damaged! ) C.
-
Page 6: Wiring Diagram
Wiring Diagram: Connecting and Operating 1. Power off all devices including your audio source and audio output device. 2. Connect your audio source device to the Transmitter's L/R or AUX Input connector with a RCA or 3.5mm stereo audio cable(cable not included).*Note: Only one input connector can be used at any one time. - Page 7 Please read safety instructions carefully before installation and operation. • Please pay close attention to all warnings and hints for this device • Do not expose this unit to rain, heavy moisture, or liquid • Do not repair the device or open the enclosure without professional guidance to avoid electric shocks.
