Konica Minolta A0HF011 User Manual

Konica Minolta A0HF011 User Manual

Printer / copier / scanner
Hide thumbs Also See for A0HF011:
Table of Contents

Advertisement

Quick Links

Download this manual

magicolor 1680MF

Printer / Copier /
Scanner User's
Guide
A0HF-9561-00A

Advertisement

Table of Contents
loading

Related Manuals for Konica Minolta A0HF011

Summary of Contents for Konica Minolta A0HF011

  • Page 1: Magicolor 1680Mf

    magicolor 1680MF Printer / Copier / Scanner User’s Guide A0HF-9561-00A...

  • Page 2: Thank You

    Center Building, 1-6-1 Marunouchi, Chiyoda-ku, Tokyo, 100-0005, Japan. All Rights Reserved. This document may not be copied, in whole or part, nor transferred to any other media or language, without written permission of KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. Notice KONICA MINOLTA BUSINESS TECHNOLOGIES, INC.

  • Page 3: Software License Agreement

    SOFTWARE LICENSE AGREEMENT This package contains the following materials provided by KONICA MINOLTA BUSINESS TECHNOLOGIES, INC. (KMBT): software included as part of the printing system (“Printing Software”), the digitally-encoded machine-readable outline data encoded in the special format and in the encrypted form (“Font Programs”), other software which runs on a computer system for use in conjunction with the Printing Software (“Host Software”), and related explanatory writ-...
  • Page 4 11. Notice to Government End Users: The Software is a “commercial item,” as that term is defined at 48 C.F.R.2.101, consisting of “commercial computer software” and “commercial computer software documentation,” as such terms are used in 48 C.F.R. 12.212. Consis- tent with 48 C.F.R.

  • Page 5: Legal Restrictions On Copying

    Legal Restrictions on Copying Certain types of documents must never be copied with the purpose or intent to pass copies of such documents off as the originals. The following is not a complete list, but is meant to be used as a guide to responsible copying.

  • Page 6: For Eu Member States Only

    For EU member states only This symbol means: Do not dispose of this product together with your household waste! Please contact the Local Authority for appropriate dis- posal instructions. In the case of a new device being purchased, the used one can also be given to our dealer for appropriate disposal.

  • Page 7: Table Of Contents

    Contents 1 Introduction ....................1-1 Getting Acquainted with Your Machine ............1-2 Space Requirements................... 1-2 Part Names ....................1-3 Front View..................... 1-3 Rear View ..................... 1-4 Front View with Option................1-5 Drivers CD/DVD ..................1-6 Printer Drivers ..................1-6 Scanner Drivers ..................1-6 Applications CD/DVD ..................
  • Page 8 Display Indications ..................2-4 Main Screen (Copy Mode) ..............2-4 Main Screen (Scan Mode) ..............2-6 Print Screen ..................2-7 Checking the Machine Status and Settings ..........2-8 PRINTER MODE Menu................2-8 TONER REMAINING .................. 2-9 T/C CHANGE ....................2-9 REPORT/STATUS Menu ................
  • Page 9 4 Using the Printer Driver ................4-1 Selecting Printer Driver Options/Defaults (for Windows) ......4-2 Uninstalling the Printer Driver (for Windows) ..........4-3 Windows Vista/XP/Server 2003/2000 ............4-3 Displaying Printer Driver Settings ............... 4-3 Windows Vista..................... 4-3 Windows XP/Server 2003 ................4-3 Windows 2000.....................
  • Page 10 Replacing the Imaging Cartridge............... 7-11 Replacing the Fuser Unit................7-15 8 Maintenance ....................8-1 Maintaining the Machine ................8-2 Cleaning the Machine ..................8-4 Exterior......................8-4 Media Rollers ....................8-5 Cleaning the Media Feed Roller ............8-5 Print Head Window ................... 8-10 Clearing the Print Head Window............
  • Page 11 x-10 Contents...

  • Page 12: Introduction

    1Introduction...

  • Page 13: Getting Acquainted With Your Machine

    Getting Acquainted with Your Machine Space Requirements To ensure easy operation, consumable replacement and maintenance, adhere to the recommended space requirements detailed below. 505 mm (19.9") 405 mm (15.9") 100 mm (3.9") Front View 160 mm 405 mm (15.9") (6.3") 100 mm 100 mm (3.9")

  • Page 14: Part Names

    Part Names The following drawings illustrate the parts of your machine referred to throughout this guide, so please take some time to become familiar with them. Front View 1—Control panel 2—Original cover 3—Tray 1 (Multipurpose tray) 4—Output tray 5—Extension tray 6—Original glass 7—Original cover pad 8—Scanner unit...

  • Page 15: Rear View

    9—Fuser unit 10—Fuser separator levers 11—Fuser cover lever 12—Imaging cartridge 13—Toner cartridge 14—Front cover Rear View 1—Power switch 2—Power connection 3—USB port Getting Acquainted with Your Machine...

  • Page 16: Front View With Option

    Front View with Option 1—Dust Cover Getting Acquainted with Your Machine...

  • Page 17: Drivers Cd/Dvd

    Drivers CD/DVD Printer Drivers Drivers Use/Benefit Windows Vista/XP/Server 2003/ These drivers give you access to all of 2000 the printer features. For details, refer to “Displaying Printer Driver Settings” Windows Vista/XP/Server 2003 for on page 4-3. 64bit Macintosh OS X (10.2.8/10.3/10.4/ 10.5) Scanner Drivers Drivers...

  • Page 18: Applications Cd/Dvd

    Applications CD/DVD Applications Applications Use/Benefit PaperPort SE This software is a document manage- ment software package that helps you scan, organize, access, share, and manage both your paper and digital documents on your personal com- puter. For details, refer to the PaperPort SE User’s Guide from the Help menu.

  • Page 19: Documentation Cd/Dvd

    Documentation CD/DVD Documentation Documentation Use/Benefit Installation Guide This manual provides installation details that must be performed in order to use this machine, such as setting up the machine and installing the drivers. Printer/Copier/Scanner User’s Guide This manual provides details on gen- (this manual) eral daily operations, such as using the drivers and control panel and...

  • Page 20: System Requirements

    System Requirements Personal computer For Windows – Pentium II: 400MHz or higher (Pentium 3: 500MHz or higher is recom- mended) For Macintosh – PowerPC G3 or later (G4 or later is recommended) – Intel processor Operating System – Microsoft Windows Vista Home Basic/Home Premium/Ultimate/Busi- ness/Enterprise, Windows Vista Home Basic/Home Premium/ Ulti- mate/Business/Enterprise x64 Edition, Windows XP Home Edition/ Professional (Service Pack 2 or later), Windows XP Professional x64...
  • Page 21 1-10 Getting Acquainted with Your Machine...

  • Page 22: Control Panel And Configuration Menu

    2Control Panel and Configuration Menu...

  • Page 23: About The Control Panel

    About the Control Panel 3 2 4 3 5 Control Panel Indicators and Keys No. Name Function Message win- Displays settings, menus, and messages. +/, keys Moves up and down through menus, options, or choices. */) keys Moves left and right through menus, options, or choices.
  • Page 24 No. Name Function Copy key/LED Enters Copy mode. Lights up in green to indicate that the machine is in Copy mode. For details on the Copy functions, refer to chapter 5, “Using the Copier”. Start (B&W) key Starts monochrome copying or scanning. Start indicator Lights up in blue when copying is possible.

  • Page 25: Display Indications

    Display Indications Main Screen (Copy Mode) No. Indication Description Copy settings Allows the current settings to be checked and the various settings to be changed. For details, refer to “Copy settings” on page 2-5. Status Depending on the situation, the machine status or an error message may appear.
  • Page 26 Copy settings Press +/, No. Indication Description Media size Indicates the media size that is selected. The media size setting can be changed with TRAY1 PAPER in the menu. For details, refer to SETUP UTILITY “TRAY1 PAPER SETUP Menu” on page 2-17. Zoom ratio Indicates the zoom ratio that is specified.

  • Page 27: Main Screen (Scan Mode)

    Main Screen (Scan Mode) Document pages can be scanned if a Start key is pressed while this screen is displayed. To scan in color, press the Start-Color key. To scan in black and white, press the Start-B&W key. For details, refer to “Scanning With the Machine” on page 6-8. In order to scan by pressing the Start key while the screen shown above is displayed, the TWAIN scanner driver, the printer driver and LinkMagic (Windows only) must be installed on the computer.

  • Page 28: Print Screen

    Print Screen When a print job is received, appears in the status PRINTER: Printing section of the main screen. To display the print screen (as shown below), press the * key while is displayed. PRINTER: Printing To cancel printing, press the Stop/Reset key when the print screen appears. Press the Select key to select No.

  • Page 29: Checking The Machine Status And Settings

    Checking the Machine Status and Settings PRINTER MODE Menu With the main screen displayed, press the * key to display the PRINTER MODE screen. From this menu, a general estimate of the amount of toner remaining in the toner cartridges can be viewed, and the printer operation mode can be switched.

  • Page 30: Toner Remaining

    TONER REMAINING A general estimate of the amount of toner remaining in the toner cartridges can be viewed. If the Select key is held down for at least 2 seconds while the screen described above is displayed, the configuration page will be printed. T/C CHANGE Switches the machine to the REPLACE MODE.
  • Page 31 Switches the machine to the P/H CLEAN P/H CLEAN MODE MODE. P/H CLEAN MODE is a mode that allows the user to clean the print head window more eas- ily. The print head window is not cleaned auto- matically. For details on cleaning the print head window, refer to “Clearing the Print Head Window”...

  • Page 32: Report/Status Menu

    REPORT/STATUS Menu To display the REPORT/STATUS screen, select in the REPORT/STATUS main screen, and then press the Select key. From this menu, the total num- ber of pages printed by this machine can be viewed. In addition, the reports can be printed. The REPORT/STATUS menu is structured as shown below. To return to the previous screen, press the Back key.

  • Page 33: Supply Status

    SUPPLY STATUS The remaining amount of toner in the toner cartridges and the remaining ser- vice life of the imaging cartridges can be displayed as a percentage. Displays the remaining amount of toner in the C TONER cyan (C) toner cartridge as a percentage. Displays the remaining amount of toner in the M TONER magenta (M) toner cartridge as a percentage.

  • Page 34: Configuration Menu Overview

    Configuration Menu Overview To display the settings menu for this machine, select in the main UTILITY screen, and then press the Select key. From the UTILITY menu, settings for the various machine functions can be changed. UTILITY Menu From this menu, various machine settings can be changed. The UTILITY menu is structured as shown below.

  • Page 35: Machine Setting Menu

    MACHINE SETTING Menu MACHINE SETTING AUTO PANEL RESET ENERGY SAVE MODE LCD CONTRAST KEY SPEED TIME TO START INTERVAL LANGUAGE TONER OUT STOP TONER LOW AUTO CONTINUE CALIBRATION 2-14 Configuration Menu Overview...
  • Page 36 Manufacturer’s default settings appear in bold. Setting AUTO PANEL RESET 30sec 1min 2min 3min 4min 5min Specify the length of time until all settings that have not been programmed, such as the num- ber of copies, are cleared and return to their default settings when no operation is performed.
  • Page 37 Setting TONER OUT STOP Select whether or not printing and copying stop when the toner has run out. is selected, printing and copying stop when the toner runs out. is selected, printing and copying contin- ues even if toner has run out. Setting TONER LOW Select whether or not a warning message...

  • Page 38: Tray1 Paper Setup Menu

    TRAY1 PAPER SETUP Menu TRAY1 PAPER SETUP Manufacturer’s default settings appear in bold. Media type LETTERHEAD THICK1 THICK2 PLAIN PAPER LABELS ENVELOPE POSTCARD Paper size The available paper sizes differ depending on the setting selected as the media type. Setting selected as the Available paper sizes media type PLAIN PAPER...
  • Page 39 Select the type and size of the media loaded into Tray 1. If CUS- is selected as the paper size, specify TOM(PLAIN) CUSTOM(THICK) settings for separately. LENGTH WIDTH The setting range for mm for , and LENGTH PLAIN PAPER mm for THICK1 THICK2 The default setting is...

  • Page 40: Admin. Management Menu

    ADMIN. MANAGEMENT Menu The ADMIN. MANAGEMENT menu is accessible only by the adminis- trator. To display the settings for this menu, select ADMIN MANAGE- , use the keypad to type in the 6-digit administrator access code MENT (default: 000000), and then press the Select key. ADMIN.

  • Page 41: Copy Setting Menu

    COPY SETTING Menu COPY SETTING QUALITY PRIORITY DENSITY PRIORITY DENSITY LEVEL AUTO MANUAL Manufacturer’s default settings appear in bold. Setting QUALITY PRI- TEXT PHOTO FINE/MIX ORITY FINE/TEXT FINE/PHOTO Select the type of document being copied. Setting DENSITY PRI- AUTO MANUAL ORITY Select the density that is normally used.

  • Page 42: Media Handling

    3Media Handling...

  • Page 43: Print Media

    Print Media Specifications Media Media Size Copy Print Inch Millimeter 8.2 x 11.7 210.0 x 297.0 B5 (JIS) 7.2 x 10.1 182.0 x 257.0 5.9 x 8.3 148.0 x 210.0 Legal 8.5 x 14.0 215.9 x 355.6 Letter 8.5 x 11.0 215.9 x 279.4 Statement 5.5 x 8.5...

  • Page 44: Types

    Types Before purchasing a large quantity of special media, do a trial print with the same media and check the print quality. Keep media on a flat, level surface in its original wrapper until it is time to load it. For a list of approved media, refer to http://printer.konicaminolta.com. Plain Paper (Recycled Paper) Capacity Tray 1...

  • Page 45: Thick Stock

    Layered Adhesive Folded, creased, curled, embossed, warped, or wrinkled Perforated, three-hole punched, or torn Too slick, too coarse, or too textured Different in texture (roughness) on the front and back Too thin or too thick Stuck together with static electricity Composed of foil or gilt;...

  • Page 46: Envelope

    Envelope Print on the front (address) side only. Some parts of the envelope consist of three layers of paper—the front, back, and flap. Anything printed in these lay- ered regions may be lost or faded. You can print continuously with envelope. However, this could affect the media feed, depending on the media quality and printing environment.

  • Page 47: Label

    Label A sheet of labels consists of a face sheet (the printing surface), adhesive, and a carrier sheet: The face sheet must follow the plain paper specification. The face sheet surface must cover the entire carrier sheet, and no adhe- sive should come through on the surface.

  • Page 48: Letterhead

    Letterhead You can print continuously with letterhead. However, this could affect the media feed, depending on the media quality and printing environment. If problems occur, stop the continuous printing and print one sheet at a time. Try printing your data on a sheet of plain paper first to check placement. Capacity Tray 1 Up to 50 sheets, depending on their size and...

  • Page 49: Printable Area

    Folded or wrinkled Printable Area The printable area on all media sizes is up to 4.0 mm (0.157") from the edges of the media. Each media size has a specific print- Printable able area (the maximum area on which Area the machine can print clearly and with- out distortion).

  • Page 50: Envelopes

    Envelopes Envelopes can only be printed on their front sides (side where the recipient’s address is written). In addition, printing on the front side in the area overlap- ping the back flap cannot be guaranteed. The location of this area differs depending on the envelope type.

  • Page 51: Loading Media

    Loading Media How do I load media? Take off the top and bottom sheets of a ream of paper. Holding a stack of approx- imately 200 sheets at a time, fan the stack to prevent static buildup before inserting it in a tray. Note Although this machine was designed for printing on a wide range of media types, it is not intended to print exclusively on a single media...
  • Page 52 Slide the media guides to pro- vide more space between them. Load the paper face up in the tray. Do not load paper above mark. Up to 200 sheets (80 g/m [21 lb]) of plain paper can be loaded into the tray at one time.

  • Page 53: Other Media

    Slide the media guides against the edges of the paper. Select in the menu, and then select TRAY1 PAPER SETUP UTILITY the settings for the size and type of paper that is loaded. See also “Print Media” on page 3-2. Other Media When loading media other than plain paper, set the media mode (Envelope, Label, Letterhead, Postcard, Thick Stock 1, or Thick Stock 2) in the driver for...
  • Page 54 Slide the media guides to pro- vide more space between them. Load the envelopes flap side down in the tray. Before loading enve- lopes, press them down to make sure that all air is removed, and make sure that the folds of the flaps are firmly pressed, other- wise the envelopes may become wrinkled or a...

  • Page 55: Loading Label Sheets/Letterheads/Postcards And Thick Stock

    Slide the media guides against the edges of the envelopes. Select in the menu, and then select TRAY1 PAPER SETUP UTILITY the settings for the size and type of media that is loaded. See also “Print Media” on page 3-2. Loading Label Sheets/Letterheads/Postcards and Thick Stock Open Tray 1.
  • Page 56 Slide the media guides to pro- vide more space between them. Load the media face up in the tray. Up to 50 sheets can be loaded into the tray at one time. Slide the media guides against the edges of the media. Select in the menu, and then select...

  • Page 57: Output Tray

    Output Tray The printed media is fed out facing down into the output tray below the control panel. This tray has a capacity of approximately 100 sheets (A4/Letter) of 80 paper. If the media is stacked too high in the output tray, your machine may experience media misfeeds, excessive media curl, or static buildup.

  • Page 58: Media Storage

    Media Storage Keep media on a flat, level surface in its original wrapper until it is time to load it. Media that has been stored for a long time out of its packaging may dry up too much and cause misfeeding. If media has been removed from its wrapper, place it in its original pack- aging and store in a cool, dark place on a level surface.

  • Page 59: Original Media

    Original Media Specifications The following types of documents can be placed on the original glass. Document type Sheets or books Maximum document size A4 or Letter Maximum weight 3 kg (6.6 lb) Observe the following precautions when placing a document on the original glass.

  • Page 60: Placing A Document To Be Copied

    Placing a Document to be Copied Lift to open the original cover. Position the document on the original glass. Document Align the document with the arrow on the left side toward the rear of the machine. Placing a Document to be Copied 3-19...
  • Page 61 Gently close the original cover. For details on copying the placed document, refer to chapter 5, “Using the Copier”. For details on scanning, refer to chapter 6, “Using the Scanner”. 3-20 Placing a Document to be Copied...

  • Page 62: Using The Printer Driver

    4Using the Printer Driver...

  • Page 63: Selecting Printer Driver Options/Defaults (For Windows)

    Choose the driver’s properties as follows: – (Windows Vista) From the Start menu, select Control Panel, and then click Hardware and Sound to select Printers. Right-click the KONICA MINOLTA magicolor 1680MF printer icon, and then select Printing Prefer- ences. – (Windows XP/Server 2003) From the start menu, select Printers and Faxes to display the Print- ers and Faxes directory.

  • Page 64: Uninstalling The Printer Driver (For Windows)

    Windows Vista/XP/Server 2003/2000 Close all applications. Choose Uninstall Program as follows: – (Windows Vista/XP/Server 2003) From the Start menu, choose All programs, KONICA MINOLTA, magicolor 1680MF, Printer, and then Uninstall. – (Windows 2000) From the Start menu, choose Program, KONICA MINOLTA, magicolor 1680MF, Printer, and then Uninstall.

  • Page 65: Windows 2000

    Windows 2000 From the Start menu, select Settings, and then click Printers to display the Printers directory. Right-click the KONICA MINOLTA magicolor 1680MF printer icon and select Printing Preferences. Displaying Printer Driver Settings...

  • Page 66: Printer Driver Settings

    Printer Driver Settings Common Buttons The buttons described below appear on each tab. Click to exit the Properties dialog box, saving any changes made. Cancel Click to exit the Properties dialog box without saving any changes made. Apply Click to save all changes without exiting the Properties dialog box. Help Click to view the help.

  • Page 67: Basic Tab

    Watermark View Click the button to display a preview of the watermark. When this button is clicked, it changes to the Printer View button. This button appears only when the Watermark tab is selected. Quality View Click the button to display a sample of the settings selected in the Quality tab. When this button is clicked, it changes to the Printer View button.

  • Page 68: Layout Tab

    Layout Tab The Layout Tab allows you to Print several pages of a document on the same page (N-up printing) Print a single copy for enlargement and print several pages Rotate the print image 180 degrees Specify image shift settings Double-Sided printing is not available with this machine.

  • Page 69: Version Tab

    Control the darkness of an image (Brightness) Adjust the saturation of printed image (Saturation) Adjust the sharpness of the printed image (Sharpness) Version Tab The Version Tab allows you to view information about the printer driver. Printer Driver Settings...

  • Page 70: Using The Copier

    5Using the Copier...

  • Page 71: Making Basic Copies

    Making Basic Copies This section contains descriptions of the basic copy operation procedure and the functions that are frequently used when making copies, such as specify- ing the zoom ratio and the copy density. Before making copies, check that the Copy key is lit up in green. If the key is not lit up in green, press the Copy key to enter Copy mode.

  • Page 72: Specifying The Copy Quality Setting

    To print color copies, press the Start-Color key. To print monochrome copies, press the Start-B&W key. Copying begins. If the Stop/Reset key is pressed while copying, JOB CANCEL appears. To stop copying, select . To continue copying, select Specifying the Copy Quality Setting Select the document type and copy density appropriate for the contents and density of the document to be copied.

  • Page 73: Specifying The Zoom Ratio

    Specifying the Zoom Ratio The zoom ratio can be specified either by selecting a preset zoom ratio or by specifying a custom zoom ratio. Selecting a Preset Zoom Ratio In the main screen (Copy mode), press the + or , key to select the cur- rent zoom ratio setting, and then press the Select key.

  • Page 74: Making Advanced Copies

    Making Advanced Copies This section contains descriptions on setting ID card copying, repeat copying and poster copying. Setting a Copy Function ID card copying, repeat copying and poster copying can be set. If a copy function other than has been set, the zoom NORMAL COPY ratio is automatically set (and cannot be changed).

  • Page 75: Repeat Copying

    The paper sizes that are available for ID card copying are A4, Let- ter and Legal. Position the document on the original glass. For details on positioning the document on the original glass, refer to “Placing a Document to be Copied” on page 3-19. In the main screen (Copy mode), press the + or , key to select the cur- rent copy function setting, and then press the Select key.

  • Page 76: Poster Copying

    Press the + or , key to select , and then press the REPEAT COPY Select key. When the How to Repeat Copy screen appears, check the settings, and then press the Select key. To print color copies, press the Start-Color key. To print monochrome copies, press the Start-B&W key.
  • Page 77 Press the + or , key to select , and then press the POSTER COPY Select key. To print color copies, press the Start-Color key. To print monochrome copies, press the Start-B&W key. After the document has been scanned, printing automatically begins. Making Advanced Copies...

  • Page 78: Using The Scanner

    6Using the Scanner...

  • Page 79: Scanning From A Computer Application

    Scanning From a Computer Application Documents can be scanned from a computer connected to this machine with a USB cable. Scanning settings can be specified and the scanning operation can be performed from TWAIN- or WIA-compatible applications. From the scanner driver, a preview can be displayed and various adjustments, such as the size of the scan area, can be specified.

  • Page 80: Windows Twain Driver Settings

    Windows TWAIN Driver Settings Load Load a saved settings file (dat file) for scanning. Save Save the current settings as a settings file (dat file). Default Return all settings to their defaults. Help icon Click to display the Help. About icon Click to display the software version information.
  • Page 81 Image size Shows the data size of the scan image. Rotation Select the orientation of the image to be scanned. Close Click to close the TWAIN driver window. Prescan Click to begin scanning a preview image. Scan Click to begin scanning. AutoCrop icon Click to automatically detect the scanning position based on the preview image.

  • Page 82: Windows Wia Driver Settings

    Windows WIA Driver Settings Color picture Select this setting when scanning in color. Grayscale picture Select this setting when scanning in grayscale. Black and white picture or text Select this setting when scanning in black and white. Custom Settings Select this setting when scanning with Adjust the quality of the scanned picture settings applied.

  • Page 83: Macintosh Twain Driver Settings

    Macintosh TWAIN Driver Settings Load Load a saved settings file (dat file) for scanning. Save Save the current settings as a settings file (dat file). Default Return all settings to their defaults. Help icon Click to display the Help. About icon Click to display the software version information.
  • Page 84 Image size Shows the data size of the scan image. Rotation Select the orientation of the image to be scanned. Close Click to close the TWAIN driver window. Prescan Click to begin scanning a preview image. Scan Click to begin scanning. AutoCrop icon Click to automatically detect the scanning position based on the preview image.

  • Page 85: Scanning With The Machine

    Scanning With the Machine The machine keys can be used to make scans. Scanning is performed with the scan settings specified in LinkMagic. To change the scan settings, change the settings in LinkMagic. In order to perform this operation, the following requirements must be met. This machine is connected to a computer using a USB cable.
  • Page 86 7Replacing Consumables...

  • Page 87: Replacing Consumables

    Replacing Consumables Note Failure to follow instructions as outlined in this manual could result in voiding your warranty. Note If an error message ( , etc.) appears, print TONER OUT I/C LIFE END out the configuration page, and then check the status of the other consumables.
  • Page 88 When replacing a toner cartridge, refer to the following table. For optimum print quality and performance, use only approved KONICA MINOLTA toner cartridges for your specific machine type, as listed in the table below. You can find your machine type and the toner cartridge part numbers on the consum- ables reorder label inside the original cover.
  • Page 89 High-Capacity Toner Cartridge - Cyan (C) A0V3 0HN For optimum print quality and performance, use only the corre- sponded TYPE genuine KONICA MINOLTA toner cartridges. Keep toner cartridges: In their packaging until you’re ready to install them. In a cool, dry location away from sunlight (due to heat).

  • Page 90: Replacing A Toner Cartridge

    Replacing a Toner Cartridge Note Be careful not to spill toner while replacing a toner cartridge. If toner spills, immediately wipe it off with a soft, dry cloth. in the UTILITY menu is set to MACHINE SETTING/TONER OUT STOP , the message (where “X”...
  • Page 91 Check that the toner cartridge to be replaced has been moved to the front. You can identify the toner cartridge by the color of the handle. Pull down the handle on the toner cartridge until the toner cartridge is unlocked and moves out slightly toward you.
  • Page 92 Note Dispose of the empty toner cartridge according to your local regulations. Do not burn the toner cartridge. For details, refer to “About Toner Cartridges” on page 7-2. Check the color of the new toner cartridge to be installed. Remove the toner cartridge from the bag. Shake the cartridge a few times to distribute the toner.
  • Page 93 Align the shaft on each end of the toner cartridge with its hold- ers, and then insert the car- tridge. Before inserting the toner cartridge, make sure that the color of the toner car- tridge to be installed is the same as the label on the toner cartridge carou- sel.
  • Page 94 Press in the toner cartridge until it locks into place. Close the front cover. Press the Stop/Reset key to reset the machine. The machine must complete a calibration cycle (less than 2 min- utes) after a toner cartridge has been replaced. If you open the scanner unit or front cover before the machine is reset, the calibra- tion stops, then starts over again after the cover is closed.

  • Page 95: Replacing All Toner Cartridges At The Same Time

    Replacing All Toner Cartridges at the Same Time Note Be careful not to spill toner while replacing a toner cartridge. If toner spills, immediately wipe it off with a soft, dry cloth. By selecting the in the PRINTER MODE menu, all toner car- EJECT MODE tridges can be replaced at the same time.

  • Page 96: Replacing The Imaging Cartridge

    Replacing the Imaging Cartridge When replacing an imaging cartridge, refer to the following table. For opti- mum print quality and performance, use only approved KONICA MINOLTA imaging cartridge for your specific machine type, as listed in the table below. You can find your machine type and the imaging cartridge part numbers on the consumables reorder label inside the original cover.
  • Page 97 Note Do not touch the wires and flat cable shown in the illustration. Grab the handle and lift it up slightly to the back, and then slowly pull the imaging cartridge out vertically. Note Dispose of the used imaging cartridge according to your local regulations.
  • Page 98 Prepare the new imaging cartridge. Note Do not touch the PC drum and the transfer belt on the imaging cartridge. Slowly insert the new imaging cartridge vertically, and then push it slightly down toward you to finish installing the imaging cartridge.
  • Page 99 Note Do not touch the wires and flat cable shown in the illustration. The machine must complete a calibration cycle (less than 2 min- utes) after the imaging cartridge has been replaced. If you open the scanner unit or front cover before the machine is reset, the cal- ibration stops, then starts over again after the cover is closed.

  • Page 100: Replacing The Fuser Unit

    Replacing the Fuser Unit For optimum print quality and performance, use only approved KONICA MINOLTA fuser unit for your specific machine type. Turn off the machine and discon- nect the power cord. Note There are extremely hot parts within the machine. Before replacing the fuser unit, wait about 20 minutes after turning off the machine, and then check that the fusing section has reached room temperature, otherwise, you may get burnt.
  • Page 101 Note Do not touch the wires and flat cable shown in the illustration. Push the blue handles back as far as possible. 7-16 Replacing Consumables...
  • Page 102 Grab the blue handles and lift the fuser unit to remove it. Note Do not touch the matching connectors of the fuser unit and the machine. Replacing Consumables 7-17...
  • Page 103 Prepare a new fuser unit. Pull the fuser separator levers forward as far as possible. Remove the fuser separator material, and then return the fuser separator levers to their original positions. 7-18 Replacing Consumables...
  • Page 104 Note Be careful not to touch the paper exit sensor and the surface of the fuser roller in the fuser unit. While lifting the fuser unit with the blue handles (one on each side), vertically insert the fuser unit. Replacing Consumables 7-19...
  • Page 105 Note Do not touch the paper exit sensor on the fuser unit. Note Do not touch the matching connectors of the fuser unit and the machine. 7-20 Replacing Consumables...
  • Page 106 After the fuser unit is firmly installed, flip the blue handles down toward you. Carefully close the scanner unit. Note Do not touch the wires and flat cable shown in the illustration. Replacing Consumables 7-21...
  • Page 107 Reconnect the power cord, and turn on the machine. 7-22 Replacing Consumables...

  • Page 108: Maintenance

    8Maintenance...

  • Page 109: Maintaining The Machine

    Maintaining the Machine CAUTION Read all caution and warning labels carefully, making sure to follow any instructions contained in them. These labels are located on the inside of the machine’s covers and the interior of the machine body. Handle the machine with care to preserve its life. Abuse handling may cause damage and void your warranty.
  • Page 110 Do not cover the machine immediately after using it. Turn it off and wait until it cools down. Do not leave the machine’s covers open for any length of time, especially in well-lit places; light may damage the toner cartridges. Do not open the machine during printing.

  • Page 111: Cleaning The Machine

    Cleaning the Machine CAUTION Be sure to turn off the machine and unplug the power cord before cleaning. However, be sure to turn on the machine when cleaning the print head window. Exterior Control Panel Ventilation Grill Machine Exterior Original Glass Original Cover Pad Cleaning the Machine...

  • Page 112: Media Rollers

    Media Rollers The accumulation of paper dust and other debris on the media rollers can cause media-feeding problems. Cleaning the Media Feed Roller Open the scanner unit. If there is paper in the output tray, remove it, and then fold up the out- put tray before opening the scanner unit.
  • Page 113 Grab the handle and lift it up slightly to the back, and then slowly pull the imaging cartridge out vertically. Note Do not touch the PC drum and the transfer belt on the imaging cartridge. Position the removed imaging cartridge horizontally as shown in the illustration at the right.
  • Page 114 Clean the media feed rollers by wiping them with a soft, dry cloth. BOTTOM VIEW CAUTION The area around the fuser unit is extremely hot. Touching anything other than the indicated levers may result in burns. If you get burned, immediately cool the skin under cold water, and then seek professional medical attention.
  • Page 115 Note Decreased print quality may result if the surface of the transfer roller is touched. Be careful not to touch the surface of the transfer roller. Slowly insert the imaging car- tridge vertically, and then push it slightly down toward you to fin- ish reinstalling the imaging car- tridge.
  • Page 116 Note Do not touch the wires and flat cable shown in the illustration. Cleaning the Machine...

  • Page 117: Print Head Window

    Print Head Window Continuing to use this machine with a dirty print head window can cause print quality problems. Clearing the Print Head Window With the main screen displayed, press the * key to display the PRINTER MODE screen. Press the , key to select and then press the Select key.
  • Page 118 The magenta toner cartridge has been moved to the position from where it can be replaced. Pull down the handle on the toner cartridge until the toner cartridge is unlocked and moves out slightly toward you. Remove the toner cartridge. When the magenta toner cartridge is removed, a gap is created within the...
  • Page 119 Close the front cover. The toner cartridge rotate within the machine. After the toner cartridges have finished rotating, open the scan- ner unit. Note Do not touch the wires and flat cable shown in the illustration. 8-12 Cleaning the Machine...
  • Page 120 Grab the handle and lift it up slightly to the back, and then slowly pull the imaging cartridge out vertically. Note Do not touch the PC drum and the transfer belt on the imaging cartridge. Position the removed imaging cartridge horizontally as shown in the illustration at the right.
  • Page 121 Clean the print head window by wiping it with a soft, dry cloth. BOTTOM VIEW CAUTION The area around the fuser unit is extremely hot. Touching anything other than the indicated levers may result in burns. If you get burned, immediately cool the skin under cold water, and then seek professional medical attention.
  • Page 122 Note Decreased print quality may result if the surface of the transfer roller is touched. Be careful not to touch the surface of the transfer roller. Slowly insert the imaging car- tridge vertically, and then push it slightly down toward you to fin- ish reinstalling the imaging car- tridge.
  • Page 123 Close the scanner unit. Note Do not touch the wires and flat cable shown in the illustration. Press the Stop/Reset key. 8-16 Cleaning the Machine...
  • Page 124 After the toner cartridges have finished rotating, open the front cover. Align the shaft on each end of the toner cartridge with its hold- ers, and then insert the car- tridge. Cleaning the Machine 8-17...
  • Page 125 Note Do not touch the contact indicated the illustration. Press in the magenta toner car- tridge until it locks into place. Close the front cover. 8-18 Cleaning the Machine...

  • Page 126: Troubleshooting

    9Troubleshooting...

  • Page 127: Introduction

    Introduction This chapter provides information to aid you in resolving machine problems you may encounter, or at least guide you to the proper sources for help. Printing a Configuration Page page 9-3 Preventing Media Misfeeds page 9-4 Understanding the Media Path page 9-5 Clearing Media Misfeeds page 9-5...

  • Page 128: Printing A Configuration Page

    Printing a Configuration Page In the main screen, press the + or , key to select REPORT/STATUS and then press the Select key. Press the + or , key to select , and then press the Select key. REPORT Press the + or , key to select , and then press CONFIGURATION PAGE the Select key.

  • Page 129: Preventing Media Misfeeds

    Preventing Media Misfeeds Make sure that... Media matches the machine specifications. Media is flat, especially on the leading edge. The machine is on a hard, flat, level surface. You store media in a dry location away from moisture and humidity. You always adjust the media guides in Tray 1 after inserting the media (a guide that is not properly adjusted can cause poor print quality, media mis- feeds, and machine damage).

  • Page 130: Understanding The Media Path

    Understanding the Media Path Understanding the media path will help you locate media misfeeds. 1. Output tray 2. Imaging cartridge 3. Toner cartridge carousel 4. Tray 1 (Multipurpose tray) 5. Fuser unit Media path Clearing Media Misfeeds To avoid damage, always remove misfed media gently, without tearing it. Any piece of media left in the machine, whether large or small, can obstruct the media path and cause further misfeeds.

  • Page 131: Media Misfeed Messages And Clearing Procedures

    Media Misfeed Messages and Clearing Procedures Media Misfeed Message Page Reference This message appears in the following cases. CHECK TRAY1 PAPER When no media is loaded in Tray 1 LOAD PAPER ( When a misfeed has occurred in Tray 1 (PRESS START KEY) With the first case, load media into the tray, and then press the Start key.

  • Page 132: Clearing A Media Misfeed In The Machine

    Clearing a Media Misfeed in the Machine Open the scanner unit. If there is paper in the output tray, remove it, and then fold up the out- put tray before opening the scanner unit. Note Do not touch the wires and flat cable shown in the illustration.
  • Page 133 Grab the handle and lift it up slightly to the back, and then slowly pull the imaging cartridge out vertically. Note Do not touch the PC drum and the transfer belt on the imaging cartridge. Position the removed imaging cartridge horizontally as shown in the illustration at the right.
  • Page 134 Push the fuser separator levers back as far as possible. CAUTION The area around the fuser unit is extremely hot. Touching anything other than the indicated levers may result in burns. If you get burned, immediately cool the skin under cold water, and then seek professional medical attention.
  • Page 135 Remove any misfed media. If a media misfeed occurs near the fuser unit, pull out the media from below the fuser unit, as shown in the illustration at the right. If the media cannot be removed from below the fuser unit, raise the fuser unit cover, and then remove the media from above the fuser unit.
  • Page 136 Note Do not touch the surface of the fuser roller in the fuser unit. Note Do not touch the paper exit sensor on the fuser unit. Clearing Media Misfeeds 9-11...
  • Page 137 Note Decreased print quality may result if the surface of the transfer roller is touched. Be careful not to touch the surface of the transfer roller. Return the fuser separator levers to their original positions. 9-12 Clearing Media Misfeeds...
  • Page 138 Slowly insert the imaging car- tridge vertically, and then push it slightly down toward you to fin- ish reinstalling the imaging car- tridge. Carefully close the scanner unit. Note Do not touch the wires and flat cable shown in the illustration. Clearing Media Misfeeds 9-13...

  • Page 139: Clearing A Media Misfeed From Tray 1

    Clearing a Media Misfeed From Tray 1 Carefully pull out the misfed media. If the media cannot be removed, instead of pull- ing it with extreme force, clear the media misfeed according to the proce- dure described in “Clear- ing a Media Misfeed in the Machine”...

  • Page 140: Solving Problems With Media Misfeeds

    Solving Problems with Media Misfeeds Frequent misfeeds in any area indicate that area should be checked, repaired, or cleaned. Repeated misfeeds may also happen if you’re using unsupported print media or original media. Symptom Cause Solution Several The front edges of Remove the media and even up the sheets go the media are not...
  • Page 141 (Envelope C6 and Envelope DL), load the envelopes with the flap edge toward the machine and the flap side facing down. Unsupported media Use KONICA MINOLTA-approved (wrong size, thick- media. See “Print Media” on page 3-2. ness, type, etc.) is Also, refer to http://printer. konicami- being used.

  • Page 142: Solving Other Problems

    Solving Other Problems To order KONICA MINOLTA consumables, go to www.q-shop.com. Symptom Cause Solution Machine The power cord is not Turn off the machine, confirm that the power is not correctly plugged into power cord is correctly plugged into the outlet.
  • Page 143 The job is very com- Wait. No action needed. plex. A toner cartridge for a Install a correct KONICA MINOLTA different region or an toner cartridge approved for your spe- unapproved toner cific machine. cartridge is installed...
  • Page 144 Check them for damage. If necessary, or fuser unit is defec- contact Technical Support with the tive. error information. Unsupported media Use KONICA MINOLTA-approved (wrong size, thick- media. See “Print Media” on page 3-2. ness, type, etc.) is Also, refer to http://printer. konicami- being used.

  • Page 145: Solving Problems With Printing Quality

    Solving Problems with Printing Quality Symptom Cause Solution Nothing is One or more of the Remove the toner cartridges and printed, or toner cartridges may check if any is damaged. there are be defective. blank spots The imaging cartridge Remove the imaging cartridge and on the may be defective.
  • Page 146 Symptom Cause Solution Image is too The print head win- Clean the print head window. light; there is dow is dirty. low image The copy density is Select a darker copy density. density. set too light. The media is moist Remove the moist media and replace from humidity.
  • Page 147 Remove the moist media and replace it appears. with new, dry media. Unsupported media Use KONICA MINOLTA-approved (wrong size, thick- media. See “Print Media” on page 3-2. ness, type, etc.) is Also, refer to http://printer. konicami- being used.
  • Page 148 Remove the moist media and replace it insufficient from humidity. with new, dry media. fusing or the Unsupported media Use KONICA MINOLTA-approved image (wrong size, thick- media. See “Print Media” on page 3-2. comes off ness, type, etc.) is Also, refer to http://printer. konicami- when being used.
  • Page 149 Symptom Cause Solution Abnormal The print head win- Clean the print head window. areas (white, dow is dirty. black, or A toner cartridge may Remove the toner cartridges with the color) appear be defective. color causing the abnormal image. in a regular Replace it with a new toner cartridge.
  • Page 150 Symptom Cause Solution Colors are The scanner unit or MACHINE SETTING/CALI- not register- front cover is opened in the menu to BRATION UTILITY ing properly; during the calibration. , and then perform the AIDC color colors are calibration. For details, refer to Gradations are not mixed or “MACHINE SETTING Menu”...

  • Page 151: Status, Error, And Service Messages

    Status, Error, and Service Messages Status, error, and service messages are displayed in the message window. They provide information about your machine and help you locate many prob- lems. When the condition associated with a displayed message has changed, the message is cleared from the window. Status Messages This message...

  • Page 152: Error Messages

    This message... means... Do this... The machine is scanning SCANNING the document. The machine is warming up Warming Up or AIDC is being per- formed. Error Messages This message... means... Do this... Tray 1 has run out Load media into the CHECK TRAY1 PAPER of paper.
  • Page 153 This message... means... Do this... The maximum num- Turn the machine off, MEMORY FILE FULL ber of image data and then, after a few files has been seconds, turn it on reached. again. Decrease the amount of data to be printed (for example, by decreasing the res- olution), and then try...
  • Page 154 This message... means... Do this... While data was Check the connection PC CONNECTION FAILED being sent in Scan with the computer and mode, the connec- the scanner driver sta- tion to the computer tus, and then try send- was interrupted. ing the data again.

  • Page 155: Service Messages

    This message... means... Do this... The indicated cover Close the indicated xxx COVER OPEN is open. cover. CLOSE xxx COVER The imaging car- Install the imaging car- tridge is not tridge. installed. A imaging cartridge Replace the imaging incompatible with cartridge with a correct the machine is one.

  • Page 156: Installing Accessories

    10Installing Accessories...

  • Page 157: Dust Cover

    Dust Cover The dust cover is an optional accessory. Contact your vendor or go to printer.konicaminolta.com for purchase informa- tion. When the dust cover is attached to Tray 1, the media is protected from dust, and operating noises from printing are reduced. We recommend that the dust cover remain attached when this machine is used.
  • Page 158 Appendix...

  • Page 159: Technical Specifications

    Technical Specifications Type Desktop (Full color laser beam printer-based all-in-one) Document holder Stationary Developing system Mono component development system Fusing system Heat roller system 1200 dpi × 600 dpi or Resolution 600 dpi × 600 dpi First print Simplex Monochrome 12 seconds for A4/Letter (plain paper) Full color 21 seconds for A4/Letter (plain paper)
  • Page 160 Warm-up time Avg. 30 seconds (time to return to Ready mode from Energy Save mode) Media sizes Tray 1 (Multipurpose tray) Paper width: 92 to 216 mm (3.6" to 8.5") Paper length: Plain paper: 195 to 356 mm (7.7" to 14.0") Thick stock 1/2: 184 to 297 mm (7.25"...
  • Page 161 External dimensions Height: 376 mm (14.8") Width: 405 mm (15.9") Depth: 427 mm (16.8") Weight 18 kg (without consumables) 20 kg (with consumables) Interface USB 2.0 compliant Standard memory 64 MB Technical Specifications...

  • Page 162: Consumable Life Expectancy Chart

    Consumable Life Expectancy Chart User-Replaceable Item Average Life Expectancy Toner cartridge Starter Cartridge = 500 pages (Y, M, C) 1,000 pages (K) Replacement Cartridge = Standard-capacity: 1,500 pages (Y, M, C) High-capacity: 2,500 pages (Y, M, C, K) Imaging cartridge Monochrome: 45,000 pages (Continuous) 10,000 pages (1 page per job)
  • Page 163 Index Zoom ratio ........5-4 Copy Setting menu ....2-20 Admin. Management menu ..2-19 Dust cover ........10-2 Basic tab ........4-6 Envelope ........3-5 Configuration menu ....2-13 Consumables Fuser unit ........7-15 Imaging cartridge ......7-11 ID card copy ......... 5-5 Toner cartridge ......7-2 Control panel ........2-2 Copy ..........5-2 Label ..........
  • Page 164 Thick stock ......... 3-4 Print quality ........ 9-20 Machine Setting menu ....2-14 Print screen ........2-7 Maintenance ........8-2 Printable area ....... 3-8 Media Printer driver Clearing misfeeds .......9-5 Basic tab ........4-6 Loading ........3-10 Displaying ........4-3 Path ..........9-5 Layout tab ........4-7 Preventing misfeeds ....9-4 Overlay tab .........
  • Page 165 For Windows .......6-3 Utility menu .........2-13 Admin. Management menu ..2-19 Copy Setting menu ....2-20 Machine Setting menu ....2-14 Tray 1 Paper Setup menu ..2-17 Version tab ........4-8 Watermark tab ......4-7 WIA driver ........6-5 Zoom ratio ........5-4 Index...

This manual is also suitable for:

Magicolor 1680mf
