Thermaltake AC-058-CO1OTN-C1 Installing

PCI-E Extend Cable Installing Notice 安裝注意事項
1. To prevent from damaging the cable, please do not fold the PCI-E cable
during installation.
為避免線材損壞，安裝時請勿對折PCI-E延長線
2. To get PCI-E
4
the PCI-E .0 X16 interface.
為確保排線傳輸速度，請連接主機板PCI Express
© 20 22 Thermaltake Technology Co., Ltd. All Rights Reserved.
All other registered trademarks belong to their respective companies.
4
.0 bandwidth, please ensure to plug the PCI-E cable into
Slot No.
1
2
3
4
5
6
4
.0插槽 (執行X16 模式)
Slot Description
4
.0 x1_1 slot
PCIe
4
PCIe .0 x16/x8_1 slot
4
PCIe .0 x1_2 slot
4
PCIe .0 x8_2 slot
4
PCIe .0 x1_3 slot
4
PCIe .0 x4_3 slot
