KD-02X+ ELECTRIC RIVET TOOL
Note: This instruction shows a full set of accessories for KD-02X+ on the
manual. Maybe you select some of them according to your own
need/order. Please refer to the actual kit that you purchased .

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KD-02X+ and is the answer not in the manual?

Questions and answers

Summary of Contents for minova KD-02X+

  • Page 1 MINOVA KD-02X+ ELECTRIC RIVET TOOL Note: This instruction shows a full set of accessories for KD-02X+ on the manual. Maybe you select some of them according to your own need/order. Please refer to the actual kit that you purchased .
  • Page 2 Please feel free to contact us if you have any questions or concerns. contact@minovatool.com support@minovatool.com https://www.youtube.com/@minovatool...

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS General Power Tool Safety Warnings Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"...
  • Page 4 finger on the switch or energizing power tools that have the switch on invites accidents. - Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. - Do not overreach.
  • Page 5 Do not use this tool if you do not understand these operating instructions or you feel the work is beyond your capability; contact Minova Tool or a trained professional for additional information or training. - Maintain labels and nameplates. These carry important information. If unreadable or missing, contact a Minova service facility for a free replacement.
  • Page 6 - Do not use an electric riveting machine that has a defect power switch. An electric riveting machine which cannot be turned on and off any more is dangerous and has to be repaired. - Remove the battery before making adjustments to the device, changing accessories or putting the device away.

  • Page 7: Functional Description

    FUNCTIONAL DESCRIPTION （A） Nose Piece （G） Work Indicator （B） Nose Housing （H） 18V Battery （C） Tool Hanger （ I ） AC Adaptor （D） Fault Indicator （E） Mandrel Collector （ F）Trigger ASSEMBLY WARNING: Recharge only with the charger specified for the battery. For specific charging instructions, read the operator’s manual supplied with your charger and battery.

  • Page 8: Operation

    INSTALLING THE NOSE PIECE The rivet tool comes with corresponding nose pieces for different blind rivet sizes. 1. Remove battery pack or AC/DC adaptor. 2. Remove the nose housing from the tool (recommended). NOTE: Due to the spring, it can be difficult to install the nose piece into the nose housing without first removing the nose housing.

  • Page 9: Maintenance

    Return the tool, battery pack, and charger to a MINOVA service facility for repair. After six months to one year, depending on use, return the tool, battery pack and charger to a MINOVA service facility for inspection.
  • Page 10 MINOVA MINOVA LI-ION BATTERY www.minovatool.com...
  • Page 11 Keep all the safety information and general instructions for future reference. - These safety warnings apply only for Minova lithium-ion batteries! - Only use the battery with products from the manufacturer. This is the only way in which you can protect the battery against dangerous overload.
  • Page 12 MAINTENANCE AND SERVICE Maintenance and cleaning for battery Occasionally clean the ventilation slots and the terminals on the battery using a soft brush that is clean and dry. Transport Lithium-ion batteries are subject to the Dangerous Goods Legislation requirements. The batteries are suitable for road-transport by the user without further restrictions.
  • Page 13 MINOVA Battery Charger www.minovatool.com...
  • Page 14 - Only charge Minova Li-Ion batteries with a capacity of 2.0 Ah or more ( 3 battery cells or more). The battery voltage must match the battery charging voltage of the charger. Do not charge any non-rechargeable batteries.

  • Page 15: Technical Data

    PRODUCT DESCRIPTION AND SPECIFICATIONS OF BATTERY CHARGER TECHNICAL DATA CHARGER Input 100-240V AC 50-60Hz 65W Output 21V DC 2.3A Permitted battery temperat 0-45℃ 2.0Ah 55-65min Charging time at battery caapprox 5.0Ah 150-160min Protection class OPERATION For battery powered tool, before using the tool, charge the battery as follows.

  • Page 16: Maintenance And Service

    MAINTENANCE AND CLEANING FOR BATTERY CHARGER In order to avoid safety hazards, if the power supply cord needs to be replaced, this must be done by Minova or by an after-sales service center that is authorized to repair Minova power tools. DISPOSAL Chargers, accessories and packaging should be recycled in an environmentally friendly manner.
