DayMark IT111163 Instructions

To Load Roll
Print-Head Adjustment
#3306
F O O D P R E P M A R K E R
To open the label
roll holder pull up-
wards using the hole
provided.
Open the inner
base plate. Insert
the label roll into the
holder.
Close the label roll
holder.
To adjust the print on the
labels, slacken the head
screws and move the
print head backwards or
forwards. Then re-tighten
the screw.
I N S T R U C T I O N S
1
3
5
Print Setting
7
To open the base,
pull down using
rounded end of the
base plate.
Slide the labels
face up through
the machine.
Pull the labels through
the machine, about 10
cm. Close the inner base
plate and then the outer
base plate keeping the
labels central, as shown.
To locate the indicator
on the band, move the
dial knob and select the
required digit, then push
back into place.
®
