EMME 21063-50 Use And Maintenance Manual

Portable fire extinguisher, 6 kg abc powder
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Use and Maintenance Technical Manual
Via del Molino, 40 - 52010 Corsalone (AR) - Italy - info@emme-italia.com - Tel. +39.0575.511320
Other branches Emme Antincendio s.r.l. in Italy : Milano - Padova - Roma - P.IVA/ C.F. 11208251006 - R.E.A. AR-159122
21063-50 : Portable Fire Extinguisher, 6 Kg ABC Powder
Note: image is for illustrative purpose only, the product purchased can has some difference
6 Kg powder fire extinguisher, temperature range from -30°C to +60°C, manufactured in accordance to UNI EN 3-7,
(D.M. 7.1.2005), approved Marine Equipment Directive MED 2014/90/EU, certified according to the directive for
pressure equipment PED 2014/68/EU. Manufactured according at productions checks as agreed with EN 3-10.
Quality Product certification guaranteed by Bureau Veritas Italia.
Suitable for use on fire involving electrical voltages up to 1 . 000 V, at a minimum distance of 1 meter.
APPROVED/CERTIFIED FIRE EXTINGUISHER:
File name
21063-50_Technical manual
available cylinder
Type of document
Use and Maintenance technical manual
• CYLINDER
In high-strength alloy steel,
3 pieces drawing, external powder
painting Red Ral 3000.
• EXTINGUISHING AGENT
ABC Powder
• PROPELLANT
Dehumidified air or nitrogen (N
• VALVE
M. 30x1.5, brass body, levers with
red painting Ral 3000.
ON REQUEST
• USE
A B C fire rating
with clip, code:
(solid materials, flammable liquids,
21063-50E
flammable gas).
FIRE
RATING :
Fire Extinguisher Model
Date
21063-50
28/12/2023
www.emme-italia.com
2
A
B
C
34
233
Rele.
Check
Rev.
M.R
1
).
Pag.
1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 21063-50 and is the answer not in the manual?

Questions and answers

Related Manuals for EMME 21063-50

Summary of Contents for EMME 21063-50

  • Page 1 Via del Molino, 40 - 52010 Corsalone (AR) - Italy - info@emme-italia.com - Tel. +39.0575.511320 Other branches Emme Antincendio s.r.l. in Italy : Milano - Padova - Roma - P.IVA/ C.F. 11208251006 - R.E.A. AR-159122 21063-50 : Portable Fire Extinguisher, 6 Kg ABC Powder •...

  • Page 2: Technical Specifications

    21063-50 : Portable Fire Extinguisher, 6 Kg ABC Powder TECHNICAL SPECIFICATIONS FIRE RATING 34 A 233 B C ABC powder - MAP 20 % (Pro-Twenty - ProPhos Chemicals S.r.l) EXTINGUISHING AGENT ABC powder - MAP 30 % (NTL30 - New Tech Lab)
  • Page 3 21063-50 : Portable Fire Extinguisher, 6 Kg ABC Powder COMPONENTS AND SPARE PARTS LIST Table 1 NUM. DESCRIPTION CODE NUM. DESCRIPTION CODE Valve M. 30x1.5 0212 Safety pin seal (green) 0285 O-ring valve 0201R PVC dip tube 1859 Valve stem...
  • Page 4 1) GENERAL REQUIREMENTS All Fire Fighting Fire Extinguishers produced by Emme Antincendio must be installed, inspected and maintained in accordance with the following manual and with the rules in force in the country of destination.

  • Page 5: Inspection Steps

    21063-50 : Portable Fire Extinguisher, 6 Kg ABC Powder 2) Do not through the fire extinguisher on to the direct flames. 3) This fire extinguisher is a pressurized vessel and must not be pierced, dented or subjected to external damage.
  • Page 6 21063-50 : Portable Fire Extinguisher, 6 Kg ABC Powder 5.3) Hydraulic test step At least every 10 years from the production date the fire extinguisher must be overhauled by a hydraulic pressure test in accordance with the pressure values “PT” stamped on the cylinder.
  • Page 7 21063-50 : Portable Fire Extinguisher, 6 Kg ABC Powder Executive details Inspection steps, Maintenance, Hydraulic test Remove the fire Remove the hose extinguisher from the and unload completely the bracket; check marking label fire extinguisher with and replace it if damaged, suitable tool.

  • Page 8: Spare Parts List

    For more details see web site www.emme-italia.com 6.2)Inspection/Maintenance Tools For a complete list of recommended tools see web site www.emme-italia.com. It is recommended to use instruments with controlled calibration and periodically verified (at least every 12 months) with certified sample instrument.
