TUFLOC 50-1 Manual

All TUFLOC models use identical mounting specifications.
1
4
2
2
11 11
1 1
16 16
50-1 OR 60-1
ALWAYS MOUNT TUFLOC WITH KEY IN THE DOWN POSITION.
MULLION
DOOR
DOOR
MULLION
L.H. DOOR
NOTE
EDGE OF
STRIKE
WING TO
DOOR
EDGE
LEFT HAND
AS SHOWN
RIGHT HAND
REVERSED
1406 Fifth Street SW • Canton, Ohio 44702 • Phone: 330-452-9132 • Fax: 330-452-2557 • Tufloc.com
7
6
16
1 1
2 4
4 4 16
11 1
1 3
16 2
50-2 OR 60-2
TO ASSURE BEST RESULTS,
29
32
CORNER 90-DEGREE MOUNT
With door closed, place TUFLOC into desired position. Mark location of (6) mounting
holes. Remove TUFLOC and drill mounting holes using "X" (.3970) drill bit. Mount
TUFLOC with 3/8" carriage bolts provided.
15
2
32
CORNER INVERSE 90-DEGREE MOUNT
With door closed, place TUFLOC into desired position. Mark location of (6) mounting
holes. Remove TUFLOC and drill mounting holes using "X" (.3970) drill bit. Mount
TUFLOC with 3/8" carriage bolts provided.
FLUSH MOUNT
Align edge of lock to edge of door as shown. Locate (3) holes on
MULLION
door and drill through using "X" (.3970) drill bit. Mount lock to door.
(Note: Key down.) With door closed, locate (3) holes in mullion. Drill
through and mount other wing.
11 11
1 1
16 16
3
1
3
2
50-3 OR 60-3
2 23/32"
9
4
32
11 1
1 3
16 2
1
1
3
8
8
3
4
16
11
16
1
3
2
Note: All right hand illustrated.
2 23/32"
9
4
32
1 1
3 3
2 2
1
1
