Sprite SL2-CM Use & Care Instructions

WASHER O-RINGS
Arandela Aros tóricos
Rondelle Joints toriques Joints toriques
Filter Housing Replaceable Filter
(Back) Cartridge (SLC)
Caja del filtro Cartucho del filtro (SLC)
(parte posterior) reemplazable
Boîtier de filtre Pièce de rechange
(Arrière) Cartouche de filtre (SLC)
SHOWER PURE
FOR A CLEAN
FRESH SHOWER
Essential Daily Protection
For Softer Hair and Skin
Certified by IAPMO
R&T against NSF/
ANSI 177 standard
for the reduction of
Chlorine
U.S. Patents: 5,914,043; 6,056,875; 5,152,464; 6,187,187
WIth Additional Patents Pending
INSTALLATION
NOTE:
- Install only in a shower enclosure.
- Install only in an open
non-pressurized system.
- Do not use with a shutoff valve.
- Do not install in a closed
pressurized system.
1. Remove the existing shower head
from the shower arm. Clean the
shower arm threads.
2. Hand-tighten the shower filter onto
the threaded shower arm.
3. Hand-tighten the shower head onto
the shower filter.
4. If leakage occurs, wrap the shower
arm pipe threads with Teflon tape.
OPERATION
BEFORE ENTERING THE SHOWER
1. Activate and flush the filter by
running hot water through the
shower filter for 1 minute before
using.
2. COOL TO DESIRED TEMPERATURE
BEFORE ENTERING SHOWER.
MAINTENANCE
1. Replace the filter cartridge (model
SLC) every 4-6 months or 10,000
gallons, whichever comes first or if
the water flow becomes reduced.
FILTER CARTRIDGE
REPLACEMENT
(MODEL SLC)
1. Unscrew the 2-piece filter
housing assembly.
2. Remove the used filter cartridge.
O-RINGS FLOW RESTRICTOR
Aros tóricos limitador de flujo
limiteur de débit
Filter Housing Gasket
el gásquet
Caja del filtro
(parte delantera)
joint
Boîtier de filtre
®
Download the FREE
SPRITE SHOWERS App!
To Ensure Maximum
Performance and Maintain
the Warranty of Your Filter
SPRITE SHOWERS
3. Lubricate the O-rings with a silicone
based lubricant, if needed.
4. Install a new SLC filter cartridge.
5. Reassemble and tighten the
filter housing
PERFORMANCE DATA:
MODEL SLC FILTER
CARTRIDGE
Maximum Rated Service Flow –
2.5 gallons per minute /
9.5 liters per minute
Maximum Rated Service Life –
4-6 months or 10,000 gallons /
37,854 liters (whichever comes first)
Maximum Working Pressure –
125 pounds per square inch /
860 kilo pascals
Maximum Operating Temperature –
120° Fahrenheit / 40° Celsius.
NOTE:
• While testing was performed under
standard laboratory conditions,
actual performance may vary.
• This system is to be used with
potable water only. -This system is
not Intended to be used as a drinking
water treatment unit.
• Both the system and installation
must comply with applicable state
and local regulations This Sprite
Shower Filtration System has been
tested for reduction of free chlorine.
The concentration of free available
chlorine in water entering the system
was reduced to a concentration less
than or equal to the permissible limit
USE & CARE INSTRUCTIONS
Slim-Line Shower Filter
Instrucciones de uso y cuidado
PARA SLIM-LINE FILTRO DE DUCHA
Instructions d'utilisation et d'entretien
POUR LE FILTRE DE DOUCHE SLIM-LINE
12.21
for water leaving the system.
This system has not been evaluated for
free chlorine reduction in the presence
of chloramines. Free chlorine reduction
performance may be impacted by the
presence of chloramines in the water
supply. Please contact your local water
utility to determine if chloramines are
used in treating your water.
LIMITED ONE YEAR
WARRANTY
Sprite Industries warrants the
shower filter housing only (not
the cartridge) to be free of defects
for a period of one year when
used under normal operating
conditions. At the time of purchase,
it is the owner's responsibility to
complete the product warranty
information available on-line, to
keep proof of purchase of the unit
and all replacement cartridge(s)
and to demonstrate that proper
cartridge replacement and filter
maintenance was performed as
specified in the owner's instructions.
The provision of this warranty shall
not apply to any product that was
not installed or used as intended
as per the Installation and Use and
Care instructions included with the
product. And to any product that has
been subjected to misuse, neglect,
over-tightening, lack of, or improper
periodic filter replacement, repaired
or altered by anyone other than an
authorized Sprite Industries service
representative, and will VOID the
warranty in its entirety.
Transportation charges on units
submitted for repair or replacement
under warranty to:
Sprite Industries, Inc.
1791 Railroad St, Corona, CA 92878
- shall be paid by the registered
owner. This is the exclusive remedy
and liability to consequential
damages. There are no other
warranties, either expressed or
implied, limited to the extent
permitted by law.
FOR MORE INFORMATION AND
ON-LINE REGISTRATION
Go to: www.spriteshowers.com
1791 Railroad St., Corona, CA 92880
Phone: 800-327-9137 (US Toll Free)
or 951-735-1015
