ASSEMBLY INSTRUCTION
!
ADULT ASSEMBLY REQUIRED
Read all instructions before assembly and use.
Due to the presence of small parts during assembly, keep
out of reach of children untill assembly is complete.
4N-PT762
BEST QUALITY. LOWEST PRICE. GUARANTEED
Patio Furniture Set
www.paylesshere.com
Advertisement
Related Manuals for FDW 4N-PT762
Summary of Contents for FDW 4N-PT762
- Page 1 Patio Furniture Set ASSEMBLY INSTRUCTION ADULT ASSEMBLY REQUIRED Read all instructions before assembly and use. Due to the presence of small parts during assembly, keep out of reach of children untill assembly is complete. 4N-PT762 www.paylesshere.com BEST QUALITY. LOWEST PRICE. GUARANTEED...
- Page 2 Notice: 50% Tighten before fixing all screws, Allen wrench is recommended instead of an electric drill. Place the item on a flat ground to adjust and make sure it remains stable. Tighten up all screws with tools gradually. If the screws are not aligned with holes during asembly, please loosen all the other screws to 50% and continue the assembly process.
- Page 3 Part list Right frame (3 pcs) Left frame (3 pcs) Chair back frame (2 pcs) Chair seat frame (2 pcs) Bench back frame (1 pc) Bench seat frame (1 pc) Table leg frame (2 pcs) Table side frame (2 pcs) Table glass (1 pc) Chair cushion (2 pcs) Bench cushion (1 pc)
- Page 4 Hardware list Bolt M6 x 25mm (34 pcs) Bolt M6 x 35mm (8 pcs) Washer M6 (42 pcs) Allen key M4 (2pcs)
- Page 5 STEP 1 (Chair assembly) Connect Chair back frame (C) & Right frame (A) with Bolt (1) & Washer (3) Do not tighten the screws. STEP 2 Connect part from step 1 & Chair seat frame (D) with Bolt (1) & Washer (3) Do not tighten the screws.
- Page 6 STEP 4 Put on Chair cushion (J) to complete Chair STEP 5 ( Bench assembly) Connect Chair back frame (E) & Right frame (A) with Bolt (1) & Washer (3) Do not tighten the screws. STEP 6 Connect part from step 5 & Chair seat frame (F) with Bolt (1) & Washer (3) Do not tighten the screws.
- Page 7 STEP 7 Connect part from step 6 & Left frame (B) with Bolt (1) & Washer (3) Then tight all screws after assembly finished STEP 8 Put on Chair cushion (K) to complete Bench...
- Page 8 STEP 9 ( Table assembly) Connect Table side frame (H) & 2 Table leg frame (G) with Bolt (2) & Washer (3 ) Don't tight all screws until assembly is finish STEP 10 Put on Table glass (I) to complete Table...
