Burley Thru Axle Fit Manual

1. Print this sheet on a standard 8.5"x11" letter sheet. Verify that the illustrations are to scale by using this ruler.
2. Check the thread pitch of your current axle by comparing it to the illustrations here.
1mm
3. Measure the length of your current axle using this illustration. Measure to the end of the threads.
Axle Head
mm
0 10 20
4. Use the thread pitch
Thread Pitch
and axle length to
determine which model
of Thru Axle you need.
If your axle length is not
shown for the thread
pitch you have, we do not
have a compatible thru
axle for you at this time.
IMPORTANT: This guide is intended for axles used with the hitch mounted trailers
1.5mm
30 40 50 60 70 80
Measured Axle Length
1.0 ~160-174 mm
1.5 ~172-178 mm
1.5 ~229 mm
1.75 ~174-180
1.75 ~229
THRU AXLE FIT GUIDE
1.75mm
90 100 110 120 130 140
Compatible Burley Thru Axle
12x1.0, 142-148 mm
12x1.5, 142-148 mm
12x1.5, 197 mm
12x1.75, 142-148 mm
12x1.75, 197 mm
150 160 170 180 190 200
SKU
960120
960121
960124
960122
960123
*Not to scale
210 220 230
