Part List And Hardware List
PIECE
DESCRIPTION
A
Back Rest
B
Seat Frame
Foot Connection
C
Right
Foot Connection
D
Left
E
Front Leg
1
Coarse Screw
2
Jcbc Screw
3
Screw
4
Allen Key
QUANTITY
1x
1x
1x
1x
1x
2x
50 mm
8x
M6 x 40mm
4x
30mm
1x
M4
MODEL # DNG1001C-SET2
Product Dimension: 20,08"D x 20,08"W x 34,06"H
If there are any questions relating to defects, missing parts, assembly issues
or replacements, please send a detailed email to cs@jonathany.com.
Do not tighten every single screw until all screws are fitted into all holes,
so that all screws fitted can be tightened together
JONATHAN Y
