UNITED ORTHO USA16103 Instructions For Use

360 AIR WALKER
INSTRUCTIONS FOR USE
Single Patient Use Only
BEFORE USING THIS DEVICE, PLEASE READ THE FOLLOWING
INSTRUCTIONS COMPLETELY AND CAREFULLY. CORRECT
APPLICATION IS VITAL TO THE PROPER FUNCTIONING OF THE
DEVICE.
INTENDED USE:
 Grade 2 & 3 Ankle Sprains
 Stable Fractures
 Post-Operative Use
 Trauma
 Rehabilitation
WARNINGS & PRECAUTIONS:
If you experience any pain, swelling, sensation changes, or any
unusual reactions while using this product, consult your
medical professional immediately.
CLEANING INSTRUCTIONS:
1. Remove the liner from the walker.
Hand wash liner using a mild detergent and cold water.
2.
Lay liner flat and air dry ONLY.
3.
Plastic walker shell can be washed with a damp cloth and
4.
mild detergent.
WARRANTY:
Manufacturer guarantees all products to be free from defects
in materials and workmanship for a period of 6 months from
date of purchase.
PART NUMBER:
Part
Size
Number
16103 SM
16105 MD
16107 LG
Women's
Men's
Shoe Size
Shoe Size
5 – 6 5.5 – 7
6.5 – 10 7.5 – 11
10.5 – 12 11.5 - 13
APPLICATION INSTRUCTIONS
1. While seated, release straps,
remove front shell, and place leg
into the walker. Wrap liner
around the foot and fasten
securely.
2. Wrap liner around leg and fasten
securely. Ensure that the air bulb
is centered over the leg.
3. Reattach front shell and fasten
securely.
4. Pull strap over front shell and
slide strap through the D-ring.
5. Pull on the strap to add tension
and fasten securely. Fasten all
three straps following steps 4 & 5.
Inflating/Deflating the Air Bladder
6. The knob directly below the air
bulb controls the air bladder.
Turn the knob clockwise to close
the valve, and turn the knob
counter-clockwise to open the
valve.
7. To inflate the air bladder, turn
the knob clockwise and pump
the air bulb until a snug fit is
achieved. Be sure not to over-
inflate. Deflate after each use by
turning the knob counter-
clockwise.
United Ortho Enterprises
2235 Pennsylvania St. Fort Wayne, IN 46803
Phone: 800-227-8748; Fax: 877-688-7975
www.United-Ortho.com
1
2
3
4
5
6
7
PN PL0060 REV A 0214
