Summary of Contents for Sunco DM MD S-WH
- Page 1 Lighting made better. User Manual Smart Dimmer Switch SKU: DM_MD_S-WH support@sunco.com (844) 334-9938...
-
Page 2: What's In The Box
What’ s in the Box? Smart Dimmer Wire Nuts Mounting Screws Mounting Screws Get Your Gear Pliers Flat-head Screwdriver Phillips-head Screwdriver... - Page 3 Compatiblity LED Bulb Compatible with dimmable LED light bulbs up to 150W.
- Page 4 Compatiblity CFL Bulb Compatible with dimmable CFL light bulbs up to 150W.
- Page 5 Installation Guide STEP 1 a. Turn off circuit breaker before installation. b. Take off wallplate from existing switch. c. Safely disconnect all wires from the switch. (3) Live (1) Ground (2) Neutral (4) Load...
- Page 6 Neutral (white) to the wall Neutral Live (white) and the dimmer Neutral (white) Live Live together. Light Load Live Sunco Ground Dimmer c. Use provided wire nut (B) to attach the Live Neutral Ground Neutral wire (black) to the dimmer (A) Live wire (black).
- Page 7 Installation Guide (Cont.) STEP 3 Connect the Luminaire to the Dimmer: a. Connect the luminaire Ground (green) to the wall Ground (green) and the dimmer Ground (green) together (if applicable). b. Connect the luminaire Neutral (white) to Ground Ground Neutral the wall Neutral (white) and the dimmer Neutral (white) together.
- Page 8 Installation Guide (Cont.) STEP 4 Mount the Dimmer: a. Separate the inner part of the wall plate to align the wall plate with the dimmer plate using a screwdriver. Inner plate Outer plate b. Mount the dimmer using the Mounting Screws (C &...
- Page 9 Additional Dimmer Information STEP 5 Turn on circuit breaker. Note: For your safety, the Air Gap Switch disconnects power at the light socket when changing bulbs. Pull the switch out of the in-wall dimmer to cut power at the light socket. STEP 6 To set the Smart Dimmer to pairing mode, hold down the power button for five seconds.
- Page 10 Lighting made better. support@sunco.com (844) 334-9938 REV1.0...
