**INJURY OR DEATH MAY OCCUR IF THESE INSTRUCTIONS ARE NOT FOLLOWED**
When mounting and adjusting your harness, it is vital that the sternum straps sit
across your chest and is a minimum of 4" BELOW your neckline. Please refer to
the illustration above for reference. Harness shoulder and lap straps must be
firmly tightened against the body at all times.
[For further information on harness installation, please contact customer service at 1-888-312-7667.]
Harness Installation Instructions, Rev. 2 (11/10/2011)
4
STERNUM STRAP MUST SIT AT LEAST 4"
BELOW YOUR NECKLINE. ALL LATCHES MUST
BE SECURE. HARNESS, SHOULDER AND LAP
STRAPS MUST BE TIGHTENED FIRMLY AGAINST
BODY AT ALL TIMES. FAILURE TO DO SO MAY
RESULT IN SERIOUS INJURY OR DEATH
"
MIN
Advertisement
Summary of Contents for Pro Armor A114220SV
- Page 1 **INJURY OR DEATH MAY OCCUR IF THESE INSTRUCTIONS ARE NOT FOLLOWED** ” STERNUM STRAP MUST SIT AT LEAST 4” BELOW YOUR NECKLINE. ALL LATCHES MUST BE SECURE. HARNESS, SHOULDER AND LAP STRAPS MUST BE TIGHTENED FIRMLY AGAINST BODY AT ALL TIMES. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH When mounting and adjusting your harness, it is vital that the sternum straps sit across your chest and is a minimum of 4”...
-
Page 2: Mounting Bracket Installation
Congratulations on the purchase of the very best harness on the market. You will enjoy the exclusive features that only Pro Armor harnesses provide. Features like the built in flashlight pouch which include a super bright 3 LED removable flashlight. Other unique features include a water resistant cell phone pouch to keep your phone or MP3 music device protected, close &... -
Page 3: Web Installation
NSTALLATION Belt webbing must have an unobstructed travel path. Your belts will move in the direction of impact. Make sure the area is clear of obstruction. Allow a minimum 1 inch space around the belts in the seat opening for anticipated travel. -
Page 4: Seat Belts
SEAT BELTS Essential to Driver Safety by Jennifer M. Faye The primary goal of any race car latch/lever, turn/push, and cam lock. All driver is to be the best and cross the three can be opened in 1 or 2 motions. finish line first. - Page 5 from all facets of the industry who provide open participation is the means by which comprehensive cross-section standards are fairly established. knowledge. Such diverse expertise and Participation in the program is webbing and thread to sunlight can cause purely voluntary, so this does not mean degradation of the fibers and loss of that all manufacturers not in the program restraint integrity.
- Page 6 The effectiveness of a restraint shoulder belts pull down and back on the assembly also influenced torso as they resist the forward motion of attachment techniques. The principal the driver. The resultant restraint force precaution for installing the mounting compresses the spinal column and will hardware to the vehicle is to minimize add to the stresses in the spine already bending stress in the fitting.
- Page 7 to prevent slippage off the shoulders. The reliability of a restraint system is greatly affected by the way it is installed. It is imperative to follow the installation instructions provided by the seat belt manufacturer. Also, necessity of replacing or rewebbing seat belts every two years cannot be more important.
