ALXUM AX-D100B User Manual

Multi-port Switch Game Card Reader
with Wireless Remote Control
Product Schematic Diagram
LED Light Indicator
A: 1 Game Card Slot: Red
B: 2 Game Card Slot: Orange
C： 3 Game Card Slot: Pink
D: 4 Game Card Slot: Yellow
E: Wireless Remote Control
Installation
Step 1: Snap the Switch Game Card Switcher into the Switch Dock.
Step 2: Connect the USB C cable to the Switch Dock.
Step 3: Insert the connecting plug into the game card slot on Switch
Console.
Step 4: Insert the game cards you need into the card slots
accordingly.
Tips
1. When multiple game cards are inserted into the switch game
card reader, all games will show on the display or TV screen but
it can read ONLY one game at one time.
2. When playing the game, please do NOT insert a new game card.
Or else it will exit the current game and switch to the new game
card automatically.
3. You can switch the different game by using the "switch" button or
the attached wireless remote control, Press 1 time the game will
be next.
4. Kindly be noted, the wireless remote control is including a
CR2032 li-ion battery, Alxum CANNOT replace it, please buy to
replace from the online or offline store.
Note
If the wireless remote control cannot work for the game card
reader,Please follow these Steps：
1. Long press the switch button of the game card switcher;
2. At the same time, plug the USB-C Power Cable,press and hold
the switching button for 4s,at this time the LED lights up yellow.
3. Press and hold the switch button of the remote control for about
2s for pairing,when the LED of the card reader lights up green,it
means the pairing is successful.
Why does the Switch wake up in sleepmode?
The issue occurs exclusively in Switch Docks that use a USB HUB
expansion chipset. The solution is to use an additional USB charger
instead of plugging the USB cable into the Switch dock's USB port.
Package Content
1 x Alxum Switch Game Card Reader
1 x USB A to C Power Cable
1 x Wireless Remote Control
Customer Service
2-Year Warranty
Life Time Technical Support
24H-Customer Service Support
support@alxum.com
SKU： AX-D100B
USER MANUAL
Alxum Electronics Awesome Life!
D
1
2
3
C
B
A
E
