Model 2450 Deluxe Digital Incubator Instruction Manual
Please read all instructions carefully before attempting to install and operate
your unit. Know the unit's application, limitations, and potential hazards.
Protect yourself and others by observing all safety information.
Step 1: Select Incubator Location
It is important to select a safe and stable location for your incubator. Avoid
places where direct sunlight may come into contact with your incubator. Also,
choose a location where the temperature is around 68-72 degrees F
consistently without any drafts.
Step 2: Getting Started with your Incubator
Remove the incubator from the packaging. The incubator
comes in two parts (top and bottom). The BOTTOM of
the incubator is the cover without the large observation
window and power supply cord. The TOP of the incubator
is the cover with the large observation window, power
supply cord, heating element, and the LCD display panel
with indicator lights. Plug both the power supply cord
and the automatic egg turner power cord into a
recommended GFCI outlet.
Step 3: Incubator Temperature and LCD Settings
The Deluxe Digital Model 2450 Incubator comes with a built in LCD display
panel that displays the internal temperature and humidity inside the incubator.
Attached to the underside of the LCD display is a black wire that measures the
incubator's temperature. Make sure this wire is not touching anything during
incubation. The temperature for the incubator is
preset to 100 degrees F from the factory. Using an
auxiliary thermometer is recommended to give an
additional temperature readout. Due to various
factors you may need to adjust the LCD panel
temperature with the additional auxiliary
thermometer to more accurately measure the
temperature inside the incubator.
To adjust the temperature inside your incubator,
press and hold the MODE button for 3-5 seconds.
The TEMP display will begin to flash. Next press the UP or DOWN red button as
needed to adjust the temperature accordingly. Once you have finished
adjusting the temperature press the MODE button again to adjust the days to
hatch if necessary. To finish, simply press the MODE button to exit. The set up
is complete. The ideal temperature for incubation is between 99.5 and 100.5
degrees F.
Step 4: Humidity Control and Proper Ventilation
The LCD display panel provides a humidity sensor through a red wire located on
the underside of the LCD display. The 2450 Incubator comes with E-Z Fill Water
Channels so you can add water without removing the lid. Use a turkey baster
to add 1/4 to 1/2 cup of water, preferably
warm and distilled, to the large Primary E-Z Fill
Water Channel (1) . The hygrometer should
have a relative humidity level between 50-60%
during incubation. Monitor and fill the large
Primary E-Z Fill Water Channel (1) as needed to
reach and maintain this percentage. The 3 days
prior to hatching, the humidity level should
increase to 65-75%. Add water to the small
Secondary E-Z Fill Water Channel (2) to reach
relative humidity to this range, if necessary.
CAUTION: Monitor humidity levels carefully as too much moisture may affect
electronic circuitry. Farm Innovators Inc. is not responsible for damage due to
excess humidity.
Proper ventilation is paramount during embryo development and should
increase during the hatching process. We suggest you remove one RED
ventilation plug located on the TOP cover when the chicks start to hatch. The
RED ventilation plugs are located on opposite ends of the large observation
window. After hatching, remove both RED ventilation plugs to help dry the
chicks.
Step 5: Insert and Monitor Eggs
Once the incubator has been tested for 6-8 hours and the temperature is 100
degrees F while the humidity is between 50-60%, insert your eggs with the
small end of the egg facing down. The Model 2450 Deluxe Digital Incubator
comes with a built in automatic egg turner that turns each egg 30 degrees on
both sides. The automatic egg turner tilts each egg and makes a complete cycle
once every 3-4 hours (six cycles a day). Before placing the eggs inside the incu-
bator ensure that both your hands and the eggs are sanitized. Note: Egg
Turner motor will be hot during the incubation period.
2255 Walter Glaub Drive
Plymouth, Indiana 46563
www.farminnovators.com
Continue to monitor your eggs throughout the 21 day process. If you are
incubating other bird species such as duck or turkey, adjust your DAY
setting from 21 days to the required amount. While monitoring your
incubated eggs avoid opening the incubator as much as possible. E-Z Fill
Water Channels are installed to prevent frequent opening of the incubator.
An OPTIONAL Egg Candler (Model 3300) is sold separately and available so
that embryos may be monitored during the process. We recommend
candling 3 times during the incubation process– Day 7 or 10, day 14, and
day 18. If you don't see anything at day 7 or day 10, do not discard those
eggs immediately.
Step 6: Getting Ready to Hatch
It is important to unplug the EGG TURNER power cord when there are
approximately three days left of incubation. Once the egg turner is
unplugged, remove the automatic egg turner and add more water to
increase the humidity level between 65-75% (as noted in Step 4). Next,
gently place the eggs on the metal screen located below the egg turner. As
the eggs begin to hatch, remove one RED ventilation plug located on the
TOP cover. The RED ventilation plugs are located on opposite ends of the
large observation window. After more eggs begin to hatch remove both
RED ventilation plugs to provide the chicks with more oxygen and to help
the drying process. Remember, different bird species have different
hatching days, so make sure you have adjusted your DAYS using the MODE
button (as noted in Step 3).
Once all the eggs have hatched remove them from the incubator. Make
sure the baby chicks are kept in a warm and dry place. To clean your
incubator use soap and water. Allow the incubator to air dry for several
days.
2
LIMITED WARRANTY
Farm Innovators, Incorporated has carefully inspected, tested, and
1
packaged this unit to insure safe and reliable operation. When you receive
your incubator, examine it carefully to determine there is no damage that
may have occurred in shipment. If damage has occurred, notify the
company from which you purchased the incubator. They will assist you in
replacing the unit.
The Model 2450 Deluxe Digital Incubator is guaranteed for 30 days, under
normal conditions and intended use of service, from the original date of
consumer purchase or date stamped on the unit against defects due to
materials and the company's workmanship only. The sole obligation shall
be to replace the defective unit with replacement parts or a replacement
unit. Units should be "checked for proper operation" prior to returning as
defective. Units must be returned prepaid. No liability for loss or damage of
any nature or kind, whether arising out of or from the use of the product,
whether or not defective, is assumed by Farm Innovators, Incorporated
and/or their employees.
Farm Innovators, Incorporated implies no warranty whatsoever to any
factors relating to the successful hatching of any eggs. There are numerous
factors that can lead to a successful and unsuccessful hatching of eggs. See
the following website for further incubation information:
Don't forget to buy your Model 3700 baby chick starter home!
E-Z Fill Water Channel Built in Egg Turner
Type of Bird # of Days
Turkey 28
Duck 28
Muscovy 33-35
Duck
Goose 29-31
Guinea 26-28
Pigeon 16-18
http://msucares.com/poultry/reproductions/index.html
(Optional Model 3300)
Egg Candler
Type of Bird # of Days
Ring Neck Pheasant 23-24
Mongolian Pheasant 24-25
Bobwhite Quail 23
Japanese Quail 17-18
Chukar Partridge 22-23
Peafowl 28
