GemRed 82311 User Manual

GemRed Orthopedic Digital Goniometer User's Manual
Moving
arms
BUTTON FUNCTIONS
ON/OFF/DISPLAY
Turn on and turn off the digital unit.Rotate display 180 degrees.
ZERO/HOLD
Hold the display of the measurement. Returns the display to zero.
OPERATION INSTRUCTION
1. Press ON/OFF bu on to turn on the digital goniometer.
2. To change display direc on 180 degree, short press the ON/OFF/DISPLAY bu on.
3. Press ZERO/HOLD bu on for 3 seconds to Zero the display.
4. Rotate the arms of the goniometer to take range of mo on measurements.
5. To lock the display of desired measurement, short press the ZERO/HOLD bu on.
6. When the measurement is in HOLD mode, the digital reader will not display a new measurement.
7. To take off HOLD mode, short press the ZERO/HOLD bu on.
8. To turn off the digital unit, press down the ON/OFF bu on un l the unit is turned off.
9. Automa c shut down a er 2 minutes on non-use.
REPLACEMENT OF BATTERY
IMPORTANT NOTE
If goniometer does not turn on, be sure ba ery compartment is completely closed.
Do not drop the digital goniometer on a hard surface.
Do not submerge the digital unit in water or get wet to prevent damaging the electronic components.
Do not store the digital goniometer with cleaning chemicals.
The chemical vapors may affect the electronic components of the digital unit.
Care has been taken to print the scales on the goniometer as accurately as possible.
However, these scales are not as accurate as the digital readout. If the two values do not match,
be sure to use the more accurate value from the digital display.
Display
Scales
Bu on
TECHNICAL DATA
Model No.
82311
0.5°
Accuracy
Resolution 0.1°
Battery
1XCR2032 Lithium Battery
ZERO/HOLD button
ON/OFF/DISPLAY button
