Wise 8WD505P-1-660 Assembly Instructions

LOUNGE ASSEMBLY INSTRUCTIONS
8-1/4" x 1-1/2"
SCREWS & WASHERS
NOTE
TO AVOID CROSS-THREADING
OF FASTENERS PLEASE START
ALL SCREWS BY HAND
A
•
You will have one carton containing a cushion seat
and a base with Z-Bar attached which will make a
complete set of lounge seats.
•
The only tool needed is a Phillips head screwdriver.
B
•
Lay the lounge cushions out fully extended, with the
cushion side down (see illustration).
•
Remove the 8-1/4" x 1-1/2" screws and washers.
They will be the attachment hardware to fasten the
upholstered base to the lounge cushions.
Questions? Missing Parts?
Call 1.800.759.5769
Above items are not manufactured
for commercial use.
MANUFACTURERS OF QUALITY MARINE SEATING SINCE 1960
472 WEST 9TH ST., RECTOR, AR 72461 • TOLL FREE TEL: 1.800.759.5769 • www.wiseseats.com
TWO WAY OPENING LOUNGE
( Z BAR )
THE WISE COMPANY
C
•
The upholstered base has a cross section with two
air holes in it. With the base in the inverted position
and the Z-Brackets extended as shown in the,
illustration line up the holes in the brackets with the
holes in the seat boards.
•
Place the washers and screws into the holes.
Finger tighten until you get the screws started.
•
Finish tightening the screws until you have a snug fit.
This will complete all necessary assembly.
•
Carefully turn the completed lounge over so that the
base supports the cushions. You will then be able to
fold the lounge cushions into the base in it's upright
position.
•
The lounge is now ready for installation in the boat.
WF 1003
3.25.07
