Master massage equipment 86260 Instructions

Mhp massage table warmer pad

Advertisement

Quick Links

Important-Instructions-
Do Not Destroy
This product covered by the following patent(s): US 7,180,037 B2
Instructions for MHP
Massage Table Warmer pad
Place the warmer pad on top of the massage
table. It is recommended that the end with the
controller inlet to be at the opposite end of
the table where the patient's head would be
located. Fix the pad in position with the elastic
straps on each corner and cover the warmer
pad with a sheet or large towel. Connect the
controller properly to the pad (as illustrated
below) and plug in the power chord safely
with 120Volts AC only.
If the LED displays an "F": Check all connections
that they are securely fastened. Unplug
controller from outlet and wait at least 20
seconds before plugging back into outlet.
Controller connectors
MHP International Inc.
8360 Rovana Circle, Sacramento,California, 95828, 888.710.7206*100
Start
the lower center of the controller underneath
the LED screen. The screen will light up and
Temperature Set
Controller
L e f t s e t o f ' + ' a n d ' - '
underneath the 'HEAT' sign
controls the temperature
from level 1 to level 10. The
temperature represented
b y d i e r e n t l e v e l s a s
shown on the screen is
F
indicated in the back(of
the page).
Important-Instructions-
Do Not Destroy
Temperature Level
LCD Display Centigrade Fahrenheit
1
L
37
2
2
40
3
3
42
4
4
45
5
5
47
6
6
50
7
7
52
8
8
55
9
9
57
10
H
60
5.4F (or 3℃ ) sensitivity is possible.
Right set of '+' and '-' underneath the 'AUTO
OFF' sign controls the duration of heating
before the warmer pad shut itself down
1 hour however if you need longer or shorter
usage you can simply tap '+' or '-' to preset
Once it shut down automatically you have to
push the on/o button again if you want to
restart. This function allows you to not worry
about forgetting to turn o the warmer pad
unintentionally.
List of Cautions
Do not use this pad on an infant, a helpless
person or anyone insensitive to heat;
Do not tuck in wired area of this pad or fold it
while being used;
Do not use pins as they might damage the
wiring;
Always turn o the pad when it's not being
used;
Keep the controller away from drafty areas
that might become damp or wet such as an
open window;
Do not use this pad with a rocking chair,
recliner or any movable furniture;
Do not tuck this pad in a sofa;
MHP International Inc.
8360 Rovana Circle, Sacramento,California, 95828, 888.710.7206*100
Do not dry clean this pad because cleaning
solvents may damage the insulation outside
98.6
104.0
the wiring;
107.6
For Canadian users Do not use the pad in a
113.0
hotel, motel or other institutions;
116.6
122.0
Do connect any other controllers to this pad
125.6
other than MHP's;
131.0
Do not use the pad in or around water;
134.6
140.0
To clean the controller, wipe it with a damp
cloth and mild detergent;
Do not immerse the controller or Spray with a
cleaning solution.
Disconnect the controller from the pad before
laundering the pad;
If malfunction of the pad is observed stop
using it immediately and contact MHP for
consultation;
Limited One Year Warranty
MHP International warrants to the original
purchaser that this product is free from
defects in material, design and craftsmanship
for a period of one year from the date of
purchase. If the product is determined to be
defective during the warranty period, MHP
International agrees to repair or replaces the
Massage Table Warmer Pad if you call us at our
customer service hotline: 888.710.7206* 100
Attention:
This warmer pad may not feel hot to the
touch as the level of heat is designed to feel
warm only when LAYING or SITTING on top
of it.
