Summary of Contents for FORIOT LCR-TC1
- Page 1 Features Performance parameters Component Range Parameter Description Type hFE(DC Current Gain),Ube(Base-Emitter Voltage),Ic(Collector Current), Iceo(Collector Cut-off Current(IB=0)), Ices(Collector short Current), Uf(Forward Voltage of protecting diode) Forward voltage drop, junction capacitance, reverse leakage current diode forward voltage <4.50V double diode forward voltage 0.01-4.50V Forward voltage drop, reverse breakdown voltage (Transistor Test Area)
-
Page 2: Transistor Tester
Transistor tester Detect transistor Automatic detection of NPN and PNP bipolar In the power off state or the test is completed, put the test element into the transistor test area of transistors.N-channel and P-chmnnel test seat, and press the locking handle, short press the multifunction key, the tester automatically MOSFETs,JFETs diodes(including double Diodes) measure, graphical display of measurement results when testing is complete. -
Page 3: Automatic Calibration
Note: Do not put components in the Transistor test area, otherwise the Zener diode cannot be tested! IR decoder After the component test is completed, point the infrared remote control at the "IR" test hole of the tester, press the remote control button, the tester will display the user code and data code after successful decoding, and display the corresponding infrared waveform. -
Page 4: Battery Charging Circuit
The charging interface is a standard Micro USB interface, please use an external 5V power supply or USB power supply for charging. Note: When the charging indicator is red, it means charging, and green means charging is complete. Shutdown Battery charging circuit Automatic shutdown after timeout When the component test is completed or the infrared decoding is completed, and the automatic The charging interface is a standard Micro USB interface, please use an external 5V power... - Page 5 symmetrical structure of this semiconductors. You can notice this problem with the elect, that the display shows the same layout with the same parameters, if the Source and Drain pinsare swapped. 5. The output current of the tester is 6MA/voltage <5V. High-power IGBTs, thyristors, and Darlington tubes that require higher current/higher voltage drive may not be measured.
