Aideepen 1200W 20A DC Converter Boost Car Step-up Power

Supply Module 8-60V to 12-83V

Specifications:

Module type: 1200W Boost Constant Current Module(Non-isolated)

Input voltage range: DC10-60V (direct input 10-60V without jumper cap selection voltage)

Input current: 20A (MAX)

exceeds 15A, please add fan cooling (add fan input current can reach 25A when the fan

input voltage is 12-24V)

Static working current: 15mA (12V liter 20V, the output voltage, the higher the current will increase too quiet)

Output voltage: 12-83V continuously adjustable (default output is adjusted to 19V shipment, please adjust to other

voltage values.) 12-83V fixed output (for bulk customers)

Output current: 18A MAX More than 10A, please strengthen the heat dissipation (related to the input and output

voltage difference, the larger the differential pressure, the smaller the output current)

Constant current range: 0.5-18A (+/-0.3A)

Low battery protection: yes (9-50V adjustable)

Working temperature: -40~+85 degrees (enhance heat dissipation when the ambient temperature is too high)

Working frequency: 150KHz

Conversion efficiency: 92%-97% (efficiency and input and output voltage, current, pressure related)

Module size（about）: 140mm*60mm*50mm

Smart Protection:

Input overcurrent protection: Yes (input over 25A, automatic protection, power does not boost)

Short circuit protection: Yes (input 30A fuse) Double short circuit protection, safer to use.

Input reverse connection protection: Yes (150A power MOS tube anti-reverse. Can be reversed for a long time)

Wiring method: 4 3mm copper columns, terminal block (please use high current pure copper wire)

Output power: = input voltage * 20A, such as: input 12V * 20A = 240W The maximum power when inputting 12V is

240W

Input voltage *20A

For example: input 24V * 20A = 480W, that is: the maximum power is 480W when inputting 24V

Guide:

Entering low battery protection:

mainly preventing battery excess discharge cells from being very low, battery

voltage can damage power modules and batteries.

For example, set 12V battery power low battery protection. On the input of the power module, input 10V voltage, and

use a screwdriver (clockwise protection voltage value, counterclockwise protection voltage low) to adjust RV1 until

the UVLO lamp is lightting. At this time, when the battery voltage drops to 10V, the battery voltage low battery

protection voltage is 10V, and the power module does not rise (the input voltage is equal to the output voltage).
