SUPERONE C48Q Product Manual

Multi-port Cigarette Lighter Adapter
Model: C48Q
USER GUIDE
How to use
1. Plug this into your car's cigarette lighter socket after the car is on.
2. Connect your device to this adapter and start to charge.
Precautions
● This product is compatible with the voltage between 12-24V. Please
do not try other models than other voltages to avoid unnecessary
danger.
● Please keep it away from children.
● Please do not disassemble it in case of damage.
● Please unplug it if you don't need to use it.
Fuse Replacement Method
Product Manual
QC3.0
QC3.0
PD 20W
Thank you for choosing this multifunctional cigarette lighter adapter. Please read
the user manual carefully before using so that you can quickly understand the
function and operation of this product.
● Features:
Two cigarette lighter sockets output 12V-24V voltage which is the
same as your car, charge your GPS and dash cam or other devices
simultaneously.
● Dual USB-A Ports
This little beast is built with two independent power management chips, which
provide QC3.0 quick charge output. Two USB-A ports can meet the fast charging
needs of electronic devices, such as Apple, Samsung, Huawei and more.
● Type-C Port Charging
20W USB C Power Delivery adopts PD PPS Tech., compatible with Apple 20W/18W
fast charging Tech., provide up to 20W output for iPhone 12/ 12 Pro/ 12 Pro Max/
12 Mini. Charging for iPhone 12 Pro Max near dead to 55%, just need 30 Minutes.
● Fuse
The bottom of this product has a replaceable 15A automotive fuse, When the
device is short-circuited, it will generate a instantaneous high voltage. After
exceeding the current limiting voltage range, this product's built-in automotive
fuse can timely cut off the current to protect the automotive circuit and electronic
equipment security.
●Cigarette lighter socket and switch
Two on/off switches control the cigarette sockets respectively so that you don't
need to plug and unplug the GPS. Reduce wear and tear, extend the lifespan of
the devices. Two sockets with the embedded blue LED lights would light up once
the vehicle power center is on (the independent switch is on), which helps you
easily find it even in the dark.
● Voltage reminder
With an intelligent LED display, indicates the car voltage properly. When the car
voltage is lower than 12V, it will warn with flashing number.
● Scope of application
This product does not limit the vehicle space, plug and play, does not need to be
fixed in the designated position, more beautiful and space-saving, easy to use.
Pull out the damaged fuse from the bottom of the machine and
insert the spare fuse inside the box into the hole to resume
normal use
Specifications
Input voltage:
USB output:
PD3.0 20W:
Working temperature:
Power Max:
Display:
Protection:
Fuse：
USB port protection:
Material:
Warranty
Our company provides customers with a warranty of 18 months
from the date of purchase.
Contact Us
For any inquires or comments regarding to our products, please
send an email to SUPERONE Support Team,
and we will response to you as soon as possible.
12V-24V
QC3.0(18W)+QC3.0(18W)
5V/3A,9V/2.22A,12V/1.67A
0℃-60℃(32℉-140℉)
180W
Blue LED Number
Over-current protection
Over-load protection
Over-heating protection
Over-voltage protection
Short-circuit protection
Automotive fuse 15A
8.8A+/-0.3 error
ABS
