ANYCOMMAND ACR-01 Manual

ANYCOMMAND
SETUP
POWER
TEMP/TIME
MODE FAN AUTO
1 2 3
SLOW MED FAST
4 5 6
SLEEP TIMER SAVER
7 8 9
CANCEL
0
ANYCOMMAND
Your ANYCOMMAND Universal Air Conditioner Remote, controls
most air conditioner brands available today. The remote is simple to
set up - just follow the three easy steps below.
1. Press and hold the SETUP button until the RED indicator
remains on.
2. Release the SETUP button.
3. Enter the 4 digit code from the library code table.
For a valid code, the RED indicator turns off after the last digit is
entered. For an invalid code, the RED indicator flashes rapidly for
CR2032 + UP
three seconds before going off.
Searching for Codes
If your air conditioner does not respond after you have tried all the
codes for your brand, or if your brand is not listed, try searching for
your code by following these steps:
1. Manually turn on the air conditioner to be controlled.
2. Press and hold the SETUP button until the RED indicator stays
on, then release the SETUP button.
3. Press and release digit button "8".
4. Press the POWER button repeatedly (up to 50 times) until the air
conditioner to be controlled responds. The RED indicator blinks
off with each button press.
5. Press and release digit button "1" to install the code.
To reset the remote to the factory settings
1. Press and hold the SETUP button until the RED indicator remains
on, then release the SETUP button.
2. Press and hold the SETUP button until the RED indicator blinks,
then release the SETUP button.
3. Press and release digit "0".
4. Press and release the SETUP button.
ANYCOM Products USA LLC | 1356 Broadway, NY, NY 10018 | 1-855-855-0294
BUTTON FUNCTIONS:
SETUP: Used to set up the remote.
POWER: Turns your air conditioner on and off.
UP/DOWN ARROWS: Increases/decreases temperature or time (when setting timer).
SETUP
MODE: Select operating mode, such as auto, cool, dry, fan, etc.
FAN: Sets fan On/Off and speed options.
POWER
AUTO: Selects fan and swing options when air conditioner is on.
TEMP/TIME
SLOW: Sets fan speed to slow or low setting.
MED: Sets fan speed to medium setting.
MODE FAN AUTO
FAST: Sets fan speed to fast or high setting.
1 2 3
SLOW MED FAST
SLEEP: Select your sleep setting options.
4 5 6
SLEEP TIMER SAVER
TIMER: Lets you control your timer on or set options.
7 8 9
CANCEL
SAVER: Turns energy saver on/off.
0
CANCEL: Timer cancel, stop or off setting.
ANYCOMMAND
NOTE: Not all functions are supported by all air conditioners.
BEFORE USE: Remove the pull tab from the pullout tray on the bottom edge of the
remote. When replacing the battery, use a CR2032 lithium battery. Insert positive
facing up. Replace the battery if the red indicator doesn't turn on when you press the
buttons.
CR2032 + UP
ADMIRAL .....................................................................................................................1653
AIRWORKS .................................................................................................................1668
ALEN .................................................................................................................. 1670 1668
AMANA ........................................................................................................................1652
AMCOR ........................................................................................................................1676
ARCTIC KING .................................................................................................. 1668 1667
BEAUMARK ..................................................................................................... 1668 1667
CARRIER......................................................................................................................1653
CLIMETTE....................................................................................................................1653
COMMERCIAL COOL ......................................................................... 1650 1674 1673
COMFORT-AIRE ........................................................................................................1655
DAEWOO ....................................................................................................................1668
DANBY .............................................................................................................. 1653 1650
DELONGHI ........................................................................................................1677 1653
EDGESTAR ........................................................................................................ 1674 1673
EVERSTAR ............................................................................................. 1672 1668 1667
FEDDERS ....................................................................................................................1653
FRIEDRICH ..............................................................................................1662 1674 1673
FRIGIDAIRE ..................................................................................................... 1654 1668
GE .................................................................................................... 1663 1661 1660 1655
GOLDSTAR .................................................................................................................1655
HAIER ........................................................................ 1664 1652 1651 1650 1674 1673
HAMPTON BAY .........................................................................................................1655
HEAT CONTROLLER INC ............................................................................1655 1653
HISENSE ......................................................................................................................1653
KELON ..........................................................................................................................1653
KENMORE ...................................................................................................................1655
KOLDFRONT ............................................................................................................. 1650
LG ...................................................................................................................................1655
MAYTAG .......................................................................................................................1653
MIDEA ................................................................................................................ 1668 1667
MITSUBISHI ................................................................................................................1669
MOVINCOOL ..............................................................................................................1667
NWT ................................................................................................................... 1653 1650
PANASONIC .................................................................................................... 1658 1655
PELONIS ........................................................................................................... 1668 1667
POLARWIND ................................................................................................... 1668 1667
ROYAL SOVERIEGN ...................................................................................... 1674 1673
SAMSUNG .................................................................................................................. 1660
SANYO .............................................................................................................. 1666 1665
SHARP ..................................................................................................... 1659 1657 1654
SOLEUS AIR ......................................................................................................1678 1671
SUNBEAM ...................................................................................................................1653
SUNPENTOWN ................................................................1676 1675 1653 1668 1667
SPT ........................................................................................1676 1675 1653 1668 1667
TOYOTOMI ........................................................................................................ 1674 1673
WESTPOINTE ................................................................................................. 1668 1667
WHIRLPOOL ..............................................................................................................1656
WINDCHASER ................................................................................................. 1674 1673
ZENITH .........................................................................................................................1655
Model ACR-01
