Oceanstar XBS1484 Manual

3-Bag Bamboo Laundry Sorter
A. B. C.
Bamboo Bamboo Bottom
Cane x 2 Grid Shelf x 1
Cane x 2
G
F
B
A
STEP 1.
Use screw nut (F) and screw (G) to connect bamboo canes (A) and (B) to form an X Shape. Use wrench
(L) to tighten. (Make sure screw nut (F) is on the same side with the smaller hole on the cane and NOT the big hole).
E
H
STEP 3.
Insert wire handles (E) through the bag loops (H) and place onto the horizontal tube (D).
1.
Two adults are recommended for ease of assembly. Use care when handing.
2.
Assembly recommended on a soft surface, such as carpet, to avoid scratching flooring finish.
3.
Discard the black circular plastic pieces. These are used to separate the shelves for shipping purpose.
E.
D.
Wire
Horizontal
Handle x 6
Tube x 2
B
A
Package Contents
G. H.
F.
Screw x 2
Screw Nut x 2
STEP 2.
Keep the X bamboo canes standing up. Use screws (J) to connect the grid shelf (C) onto the bottom holes
of the X canes. Use screws (J) to connect the horizontal tubes (D) onto the top holes of the X canes. Use wrench (K)
to tighten all the screws. (Make sure screw (J) goes in through the side with the bigger hole on the X cane).
I.
J.
Bag x 3 Feet Leveler
Screw x 8
Pre-Screwed x 4
D
C
J
CAUTION: Do not allow children to climb or play in or
around the shelves.
Item# XBS1484
K.
L.
L Wrench x 1
Wrench x 1
J
J
