Dripex P1001 Installation Instructions

Please read the manual first
before assembling or using the fence.
ITEM NO.: P1001
Qty: 1 SET
Specifications: 150*200CM(59*78.74inch)
Material: Oxford Cloth/ Linen, Spong, Steel Pipe, Plastic
Application: Mainly indoor use, such as liveroom, bedroom
996 Pipe 745 Pipe
1 2
4 5
Straight Pipe Straight Tee
• Check the number of accessories！
Accessories shall be classified and placed for standby.
• Install clockwise from end to end！
• Refer to Structural Diagram.
• Confirm whether the site size is appropriate.
1
1. Place the fence cloth cover according to the
specification and shape.The long and short sides
of the cloth sleeve shall be symmetrical.
2
2. Thread tube (4pcs 996 Pipe and 4pcs 745 Pipe)
into the corresponding position at the bottom of
the fence cloth sleeve. Connect the bottom to the
straight pipe, and then connect the sucker tee.
Module
996 Pipe
745 Pipe
620 Pipe
Straight Pipe
Straight Tee
Sucker Tee
Handle
Storage Bag
620 Pipe
3
6
Sucker Tee
3
3. Thread 8pcs vertical tube(620 Pipe) into the
fence cloth sleeve in order. Insert the vertical
Tube into the corresponding the straight pipe
and the sucker tee at the bottom.
4
4. Thread tube (4pcs 996 Pipe and 4pcs 745
Pipe) into the corresponding position at the
top of the fence cloth sleeve. Connect the top
to the straight pipe, and then connect the
straight tee.
Finally install the tube and connector corresponding to
the zipper handrail. Install Corner Protector and check
that all parts are installed correctly.
Quantity Length
Picture Display
(mm)
8 996
8 745
8 620
8 110
4
4
1
1
