- Page 1 INSTALLATION MANUAL BATHROOM MEDICINE CABINET...
-
Page 2: Before Installation
BEFORE INSTALLATION Thank you for choosing our products. To ensure the best possible experience, please read carefully and follow the instructions provided below before assembling and installing the product. Important Safety Instructions: ● Assembly by two or more adults is highly recommended. ●... -
Page 3: Accessories List
CONTACT US After opening the package, please inspect the product immediately and see if there is any damage or missing parts. If there is, please contact us by sales@keonjinn.com or find us at Amazon. ACCESSORIES LIST Wall Wall Bubber Screw... - Page 4 SINGLE-DOOR CABINET: WALL-MOUNTED 1. Place the medicine cabinet against the wall and mark the placement of the cabinet. Confirm the locations for drilling holes with the positioning ruler and a level ruler, and use a marker to mark the spots ①②③④ on the wall. Note: Please hang the cabinet at least 3 inches above the faucet.
- Page 5 3. One person lifts up the medicine cabinet and aligns it to the screw holes (①), while the other person secure the medicine cabinet to the wall with the 4 screws (②). ① ② SINGLE-DOOR CABINET: RECESS-MOUNTED 1. Place the medicine cabinet against the wall and mark the placement of the cabinet.
- Page 6 2. Use an electric drill to punch holes at the marked spots (①), then apply the 4 wall anchors with a hammer (②). ① Cutout Dimension Reference: Size Height(in) Width(in) Depth(in) 16" x 24" ≥ 25/32 31/32 20" x 26" ≥...
- Page 7 4. Put the cabinet in the cutout together (①) and secure the cabinet with screws (②). ① ② DOUBLE/TRIPLE-DOOR CABINET: WALL-MOUNTED 1. Before installation, remove the cabinet door first by detaching the hydraulic hinges. ① ② Press to detach 2. Place the medicine cabinet against the wall and mark the placement of the cabinet.
- Page 8 3. Use an electric drill to punch holes at the marked spots (①), then apply the 6 wall anchors with a hammer (②). ② ① ø Thickness of Wall Recommended Drill Bit 1/4" (6mm) drill bit, ＞ 5/8" (16mm) drilling depth in 1 (50mm) 31/32"...
- Page 9 5. Reinstall the cabinet door by attaching hydraulic hinges. How to Adjust Hydraulic Hinges Turn screw ① to release the mounting plate from the cabinet, ③ allowing the door to be moved up ② ① ① and down; Turn front screw ② to adjust the depth of door overlay;...
- Page 10 2. Place the medicine cabinet against the wall and mark the placement of the cabinet. Draw a line on the wall with a level and marker to indicate where the cabinet bottom is. Note: Please hang the cabinet at least 3 inches above the faucet. 3.
- Page 11 4. Mark the spots for drilling on the wall (①), punch holes at the marked spots with an electric drill (②), and apply the 4 wall anchors with a hammer (③). ① ② ③ ø Thickness of Wall Recommended Drill Bit 1/4"...
-
Page 12: Product Dimensions
101 x 76 x 13 cm Asymmetrical Double-door 48" x 30" 121 x 76 x 13 cm Triple-door 60" x 30" 152 x 76 x 13 cm Triple-door If you have any questions, please feel free to contact us via sales@keonjinn.com...
