Byte Brothers BSX200 Manual

BSX200 LOW COST BUTT SET
HANDLES THE MOST
CRITICAL BUTT SET REQUIREMENTS
IN A LIGHTWEIGHT KIT
DIAL TONE
DIAL OUT
CALLER ID
LAST NUMBER REDIAL
ON/OFF HANGUP BUTTON
FLASH BUTTON
DTM AND FSK SUPPORT
LAST NUMBER REDIAL
3 TYPES OF LINE PLUGS
OPERATION
Connect the handset to the phone line using one of the three methods:
1. Alligator clips
2. RJ11 connector
3. Punch down block adapter
Turn the handset ON/OFF using the center button.
Use the number pad to dial a number. Press Redial to dial the same
number again.
Incoming calls will display Caller ID (if the service is enabled)
WARRANTY: The manufacturer warrants to the original consumer that this product is in good
working order for a period of one year from the date of purchase. Unless the product has been
damaged by the user, the product will be repaired or replaced without charge for either parts or
labor during this period. Repair or replacement as provided under this warranty is the exclusive
remedy of the purchaser.
TECH SUPPORT: USA based tech support provided on all products
CONTENTS
Telephone handset with RJ11 connector
Two adapter cables (alligator clips, punchdown block)
RJ11 coupler
Pouch
© 2014 Byte Brothers, Inc.
Assembled in the USA
from domestic
and foreign parts
WWW.BYTEBROTHERS.COM
Cable and Device Testers
Cable and Device Testers
7003 132nd Place SE, Newcastle, WA 98059 USA
(425)917-8380 FAX (425)917-8379
