Thank you for choosing ForgingMount product! We strive to provide the best quality
and services for our customers. Would you kindly share your experience
on Amazon if you are satis ed? If you have any questions, please feel
free contact us.
Email
Mobile TV Cart
Instruction Manual
forgingmount888@163.com
We're ready to help!
FM6613
v1.0
1. Compatible for 23"-55"TV
2. Max VESA:400X400mm
3. Max Loading: 55Lbs(25kg)
4. Shelf loading: 11Lbs(5kg)
Advertisement
Summary of Contents for Forging Mount FM6613
- Page 1 1. Compatible for 23”-55”TV 2. Max VESA:400X400mm 3. Max Loading: 55Lbs(25kg) FM6613 4. Shelf loading: 11Lbs(5kg) Thank you for choosing ForgingMount product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satis ed? If you have any questions, please feel free contact us.
- Page 2 forgingmount888@163.com forgingmount888@163.com forgingmount888@163.com...
- Page 3 Supplied Parts and Hardware Supplied Parts lower pole upper pole castor...
- Page 4 Allen key wrench TV plate TV bracket...
- Page 5 Step 1 Assemble the castor Tube Connector Square Tube Tube Connector wrench Screw the Castors (8) to the Square Tube (1) and Tube Connector (1) using Wrench (14). Turn this nut to adjust the height of castor...
- Page 6 Step 2 Assemble the Base Tube Connector Square Tube M6x16 Allen key Secure the Square Tubes (1) to the Tube Connector (2) using bolts and Allen Key (14).
- Page 7 Step 3 Connect the Upper Pole (5), Middle Pole (4) and Lower Pole (3). Lower Pole Middle Pole Upper Pole Pole Connector Allen Key 3-1. Connect the two parts of Pole Connector (6) . Note: The convex grooves on 3-2. Tighten the screws to the pole connector (6) should secure three poles.
- Page 8 Secure the two Square Tube to the Tube Connector Step 4 (2) using bolts (10,11) and Allen Key (14). M8x20 M6x16 Allen Key...
- Page 9 Secure the "C" Clamp soft pad ( 18) and Shelf (17) to the Step 5 Middle Pole (4) using bolts (9) and Allen Key (14). Shelf M6x16 “C” clamp soft pad Allen key...
- Page 10 Step 6 Secure the TV Plate (15) to the Upper Pole. M8X16 D8 iron washer M6X60 D8 plastic washer Allen key TV Plate...
- Page 11 M-A x4 M-B x4 M-C x4 M-D x4 15mm 30mm M-E x4 M-F x4 20mm φ4/φ6/φ8 x4...
- Page 12 M-G x8 M-H x8 Φ8x5mm Φ8x10mm forgingmount888@163.com...
- Page 13 M-A/M-C/M-E M-B/M-D/M-F M-G/M-H Alternate Spacer Setups...
- Page 14 M-B/M-D/M-F M-G/M-H M-A/M-C/M-E Alternate Spacer Setups M-G/M-H Alternate Spacer Setups M-B/M-D/M-F M-G/M-H...
- Page 16 CAUTION: Avoid potential personal injury or property damage! Make sure your locking screws are tightened BEHIND the mounting plate so the TV is securely fastened in place.
- Page 17 Step Step Manage the Wires...
- Page 18 FORGINGMOUNT FORGINGMOUNT forgingmount888@163.com...
