Elite Core EC-WBP-VC User Manual

WIRED BODY PACK WITH VOLUME CONTROL
USER MANUAL
THIS IS NOT A HEADPHONE
AMPLIFICATION DEVICE.
3.5 MM INPUT
IT IS A PASSIVE EXTENSION PACK WITH
A VOLUME ATTENUATOR.
The Elite Core Wired Body Pack with for
Headphone Extension is an ultra-durable
3.5MM to XLR adapter that features a passive
volume control knob and a heavy-duty belt
clip for use with the EC-PRO-HEX 10' or 18'
headphone extension cable.
VOLUME ATTENUATOR
TO USE THIS DEVICE:
Insert an 3 Pin, XLR cable from your audio source into the 3 pin connector
on the bottom of the Body Pack.
Next, plug in your headphones or In Ear Monitors to the
3.5mm port located on the top of the unit.
Adjust the volume of the audio with the volume control located at the top of the unit.
NOTE: This is a PASSIVE extention body pack with a volume attenuator. This is not a headphone
amplification device. While it will function, using this product without a headphone amplifier will result
in a decreased volume level that may be too low for most applications.
BELT CLIP
XLR INPUT
Elite Core LLC 1191 Sturgis Road Conway, AR 72034 STE 300 855-276-2673
