Audiovox Electronics FLASHLOGIC FLC-DL-CH6 Install Manual

Hide thumbs

Advertisement

Table of Contents

audiovox electronics corp.
iNstall Guide
flc-Dl-ch6
available for : flDl1
Rev. Date: August 11, 2010
Doc. No.: ##3747##
20100811
please visit www.flash-it.com for complete product details
The brand names and logos found in this guide are property of their respective owners. Audiovox Electronics Corp. © 2010
!
NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the installed
device. This device must be installed by a certified technician. This guide has been written for
properly trained technicians; a certain level of skill & knowledge is therefore assumed. Please
review the Installation Guide carefully before beginning any work.
CH6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLASHLOGIC FLC-DL-CH6 and is the answer not in the manual?

Questions and answers

Related Manuals for Audiovox Electronics FLASHLOGIC FLC-DL-CH6

Summary of Contents for Audiovox Electronics FLASHLOGIC FLC-DL-CH6

  • Page 1 The brand names and logos found in this guide are property of their respective owners. Audiovox Electronics Corp. © 2010 NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from improper installation of this product, be that either damage to the vehicle itself or to the installed device.
  • Page 2 • • • • † Extra resis- tor and relay required. Neon 00-01 • • • • • • • • • • • • • * Brake output available ONLY with ignition ON. www.flash-it.com audiovox electronics corp. © 2010...
  • Page 3 OEM alarm equipped vehicle. OEM alarm equipped vehicle. 2. ProceeD with installation See applicable wiring diagram NOTE : ensure all connections are comPleteD anD ProPerly secureD Prior to connecting the wire harnesses to the moDule. www.flash-it.com audiovox electronics corp. © 2010...
  • Page 4 ORANGE - DATA (J1850) (NC) BLACK/WHITE PINK/BLACK (NC) DOOR & TRUNK STATUS (-) OUPUT - GREEN PINK - IGNITION (+) INPUT TACH OUTPUT (AC) - PURPLE/WHITE LEGEND Wiring connections not required when using the DBI Port. www.flash-it.com audiovox electronics corp. © 2010...
  • Page 5 THE SECOND START FEATURE THROUGH DATA, THIS WIRE MUST BE CONNECTED TO THE VEHICLE STARTER WIRE IN PARALLEL LEGEND WITH THE REMOTE STARTER (+) STARTER OUTPUT Wiring connections not required when using the DBI Port. www.flash-it.com audiovox electronics corp. © 2010...
  • Page 6 Yellow/Violet Liberty 02-04 Pink/Violet At BCM, C2 Connector, Pin #20 (See BCM image) Blue 1&2 or Violet/Black Neon 00-01 LtGreen Harness coming from driver door Blue/White Violet/Yellow 1&2 With OEM Alarm Without OEM Alarm www.flash-it.com audiovox electronics corp. © 2010...
  • Page 7 WITH OEM ALARM ONLY (NC) PURPLE/BLACK ORANGE/WHITE (NC) (NC) WHITE ORANGE - DATA (J1850) (NC) BLACK/WHITE PINK/BLACK (NC) DOOR & TRUNK STATUS (-) OUTPUT - GREEN PINK - IGNITION (+) INPUT TACH OUTPUT (AC) - PURPLE/WHITE www.flash-it.com audiovox electronics corp. © 2010...
  • Page 8 MULTIPLE WIRES WITH THE SAME COLOR. 18 19 20 21 22 23 24 25 TEST WIRES AND VERIFY PINOUT POSITION. 26 27 28 29 30 31 32 33 34 BCM LOCATED UNDER DRIVER SIDE DASH AGAINST FIREWALL www.flash-it.com audiovox electronics corp. © 2010...
  • Page 9 MULTIPLE WIRES WITH THE SAME COLOR. 18 19 20 21 22 23 24 25 TEST WIRES AND VERIFY PINOUT POSITION. 26 27 28 29 30 31 32 33 34 BCM LOCATED UNDER DRIVER SIDE DASH AGAINST FIREWALL www.flash-it.com audiovox electronics corp. © 2010...
  • Page 10 ORANGE - DATA (J1850) DOOR & TRUNK STATUS (-) OUTPUT - GREEN PINK/BLACK (NC) TACH OUTPUT (AC) - PURPLE/WHITE PINK - IGNITION (+) INPUT LEGEND Wiring connections not required when using the DBI Port. www.flash-it.com audiovox electronics corp. © 2010...

  • Page 11: Press And Hold

    Turn key to OFF position. Remove key. Turn key to ON position. Module Programming LED will turn solid RED. Procedure completed. Wait, it may take up to 20 seconds. LED will turn solid GREEN then will turn OFF. www.flash-it.com audiovox electronics corp. © 2010...

  • Page 12: Classic-Series

    PRESS AND HOLD programming button while connecting either 4-PIN standard or optional data connector. Failure to follow procedure may result with a DTC or a When LED fl ashes red, CHECK ENGINE error message. RELEASE programming button. www.flash-it.com audiovox electronics corp. © 2010...
