1. Switch display parameters
In the normal interface, short press SW to switch the display on the lower line of the
display screen, and the display content is switched between current A, power W, capacity Ah,
and time h. Long press the SW button to switch the display on the upper line of the display,
and the display content is switched between the input voltage IN and the output voltage
OUT.
2. Set the output voltage
Short press the U/I button in the normal interface to enter the interface for setting
voltage and constant current. You can see that a certain digit of the set output voltage is
flashing, turn the rotary encoder left and right to adjust the value. Short press the rotary
encoder to select which bit to set the output voltage. After the setting is completed, short
press the U/I button twice to return to the normal interface. Or it will automatically return to
the normal interface after stopping the operation for 10 seconds.
3. Set the constant current (the module output maximum current)
Short press the U/I button in the normal interface to enter the interface for setting
voltage constant current. Then short press the U/I button to switch to setting the constant
current value, you can see that a certain bit of the constant current value is flashing, turn the
rotary encoder left and right to adjust the value. Short press the rotary encoder to choose
which bit to set the constant current value. After the setting is completed, short press the U/I
button to exit the setting voltage constant current interface and return to the normal
interface. Or it will automatically return to the normal interface after stopping the operation
for 10 seconds.
4. Set the default ON/OFF status
Press and hold the U/I button in the normal interface to enter the parameter setting
interface. You can see that it displays OPEN OFF or OPEN ON. OPEN OFF means that the
output is turned off by default when power is turned on, and OPEN ON means that the
output is turned on by default when power is turned on. Long press the rotary encoder to
switch between two states. After the setting is completed, long press the U/I button to
return to the normal interface.
5. Set the threshold value for protection opening
Press and hold the U/I button in the normal interface to enter the parameter setting
interface. Short press the SW button until the protection parameters you want to set appear.
LUP—under-voltage protection threshold; OUP—over-voltage protection threshold; OCP—
over-current protection threshold; OPP — overpower protection threshold; OAP —
overcapacity protection threshold; OHP overtime protection threshold; OTP —
