- Page 1 Magsafe Car Mount User Manual How to Get Product Installation Video? Scan the QR Code Email: service@htulink.com Website: http://htulink.com...
-
Page 2: Product Diagram
Package Contents Car Mount Suction Cup Air Vent Clip Wipe Product Diagram Car Mount Clamp Arm Silicone Pad Grip Nut Release Button Bottom Tray... - Page 3 Suction Cup Suction Cup Lock Rotatable Suction Cup Bendable Arm Silicone Base Ball Joint Silicone Pad with Cable Organizer Air Vent Clip Ball Joint Non-slip Position Silicone Pad Rotation Lock Concave Groove Retractable Hook...
- Page 4 Mounting Position Dashboard Installation Windshield Air Vent Installation Installation Car Touchscreen Installation...
-
Page 5: Practical Tips
Practical Tips The suction cup is suitable for clean, flat, smooth, and non-porous surfaces. 1. Installation Spot Dashboard, windshield, air vent, and touchscreen. Windshield Plastic Dashboard Touchscreen Air Vent Leather【except faux/ synthetic leather】 or textile dash surfaces are not suitable for installing all suction cups, if you have these dashboards, please install the mount on the air vent or windshield. - Page 6 2. Tips for Using the Suction Cup Find a flat and smooth surface, clean the surface and wait for it to dry. After attaching the suction cup, press down the suction cup lock totally to fix it. In the extreme summer heat: Please install the suction cup on the dashboard or use the air vent clip, not the windshield, and keep the suction cup away from direct sunlight.
- Page 7 3. Tips for Removing the Suction Cup Pull up the "LOCK" button. Pull the tab on the suction cup to allow air to get into it to break the seal underneath. Once the seal is broken you will be able to remove it easier.
- Page 8 2. Pull down the bottom tray. 3. Put the phone, and then press the clamp arms. Installation Steps for Car Mount 1. Assemble the Car Mount Unscrew the nut and remove it.
-
Page 9: Preparation Before Installation
Insert the ball joint into the back of the holder with force, and then screw the nut tightly. Insert with force If the car mount is loose or wobbling, please retighten the nut. 2.Preparation before Installation Find the installation position: simulate the usage scenario, and match the most suitable position. - Page 10 Try to keep the arm close to the dash rather than in an overhanging situation. If you don't use this silicone pad, please remove it from this side of the ball head. 3.Suction Cup Installation Find a flat and smooth surface, clean it with a wet and dry towel, and wait for the surface to dry.
- Page 11 LOW-TEMPERATURE TIP: To increase viscosity when the temperature is below 0°C/32°F, turn on the hot air from the AC vent to heat the sucker base for 30s. Place the sucker and rotate it to a suitable view. Press the base 360°...
- Page 12 Hold down the base when adjusting bendable shape of the arm. Adjust the silicone pad to touch the dash, so that the support arm is well-supported. Try to keep the arm close to the dash rather than in an overhanging situation. 6) Leave it for 20mins to ensure the sucker is stable before use.
- Page 13 Pull up Rinse the sucker bottom, and then air-dry it to reuse. Using with the Air Vent Clip 1. The SuitabiIity of Car Air Vent...
- Page 14 2. Air Vent Installation Insert the ball joint into the back of the holder with force, and then screw the nut tightly. 2) Turn counterclockwise to extend the hook. Insert the hook into horizontal or vertical vent. 3) Turn clockwise to lock the hook.
- Page 15 3. Tips for Using the Air Vent Clip Applicable air vent depth: 12mm-38.7mm (0.5inch-1.5inch) Left 12mm/0.5inch 38.7mm/1.5inch Turn counterclockwise to extend the hook.
-
Page 16: Frequently Asked Questions
Frequently Asked Questions Q: Why is it necessary to bend the sucker arm first before installing it on the dashboard? Firstly, since the sucker arm comes out straight and most dashboard surfaces are curved, bending the arm first will make it fit the shape of the curved dashboard better. - Page 17 big curved/ plush cloth surface or the slope of the surface is too big, it is recommended to install the mount on the windshield or to use the air vent clip. Q: How to avoid the mount shake? Please turn off the "LOCK" button after pressing the base for 5s.
- Page 18 Temperature rising makes a horrible in-car environment. Please pay attention to the safety of pets and babies. Car temps over time: OUTSIDE TEMP 30 MIN 60 MIN 70°F 104°F 113°F 80°F 114°F 123°F 90°F 124°F 133°F 100°F 134°F 143°F Email: service@htulink.com Website: http://htulink.com...
