Danner 03755 Installation Instructions

12", 24", 36" ILLUMINATED SPILLWAY
INSTALLATION INSTRUCTIONS
Model Description
03755
12" SPILLWAY
03701
24" SPILLWAY
03702
03703
36" SPILLWAY
10703
This illuminated Spillway can be used in a variety of applications. The most common installation is in self-contained waterfalls and
in decorative walls using interlocking wall blocks.
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this product. When using an electric appliance, basic precautions should be observed, including the following:
- Unplug from outlet when not in use and before cleaning or maintenance.
- Do not operate with damaged power cord.
- Do not pull or carry the product by power cord.
- If the power cord becomes damaged, remove power & replace entire LED
electrical assembly immediately.
- Use the product only for its intended use.
Grounding Instructions
This product must be connected to a grounded wiring system. If it should break down or malfunction, grounding provides a safe path of least resistance for electrical
current, reducing risk of electrical shock. It must be plugged into the outlet that is properly installed and grounded in accordance with all local codes and ordinances.
Improper connection of the equipment can result in electrical shock. Check with a quali ed electrician if you are unsure if the outlet is properly grounded. Do not
modify the plug provided with the product or use any type of plug adapter.
NOTE:
ALL DIMENSIONS SHOWN
ARE APPROXIMATE
NOTE:
MOUNTING HEIGHT ABOVE WATER IS EQUAL
TO THE WIDTH OF THE SPILLWAY.
(e.g. A 36" SPILLWAY SHOULD BE MOUNTED
~ 36" ABOVE THE WATER LEVEL.
pump not included
Wall Cap
E.G.Danner Mfg., Inc. will repair or replace any unit found to be defective within one year of original purchase. Cutting or
altering cord, removing or defacing the product labels voids any warranty consideration. For warranty repair, return
only the part that is defective to our factory. Please include a dated proof of purchase.
Damages or injuries resulting from negligence, shipping, handling, improper installation, maintenance or misuse of the
product are not covered by warranty. This Warranty gives you speci c legal rights. You may have other rights which vary
from state to state.
DANNER Mfg. INC. • Islandia, New York 11749
Recommended pump size
1000 GPH MAG DRIVE
2400 GPH MAG DRIVE
3600 GPH MAG DRIVE
Wall Cap
Pump
Liner
LIMITED WARRANTY
631-234-5261 www.dannermfg.com
Inlet size
1 1/4" Female
w/ STEP BARB FITTING
1 1/2" FEMALE
- Close supervision is necessary when used near children.
- Only connect unit to properly grounded outlet (See Grounding Instructions).
- Only use manufacturer's attachments and spare parts.
½"
1"
2 / "
12", 24" or 36"
½"
(12" ONLY)
3 "
5"
3 "
1/8
1"
