iHome iHRK-500LTMS Manual

MULTI-LINK CONNECTION
iHRK-500LTMS
First ensure all speakers are sufficiently
charged. Press to power ON and hold the
power button down for 3+ seconds to
check battery charge status.
Power OFF when done.
First time connecting?
Skip this and proceed to Step 1
If you've already connected to any LTMS
speakers from your playback device, go to
Bluetooth settings and under
"iHome iHRK-500LTMS" and select
"Forget this device".
1
STEP 1: Power ON speaker you wish to be your master speaker. This will be the main speaker you connect
to, Link speakers will connect to this master individually.
MASTER
2
STEP 2: Once powered on you likely will see a flashing
BLUE LED, while attempting to pair to Bluetooth. If light
is flashing WHITE then this speaker is currently assigned
to be LINK speaker, proceed to Step 3.
If flashing BLUE/WHITE, this speaker is already assigned
as Master. Skip Step 3 and Proceed to Step 4.
"BATTERY
100%"
BLUETOOTH
MY DEVICES
i
iHome iHRK-500LTMS
FORGET THIS DEVICE
BLUETOOTH
MY DEVICES
iHome iHRK-500LTMS
"PAIRING"
FORGET THIS DEVICE
FLASHING BLUE
3
STEP 3: Whether showing BLUE or
WHITE LED need to quickly DOUBLE
CLICK the PAIR button to assign as
MASTER speaker. You should hear
"Broadcast Audio Enabled" and LED
will turn to a BLUE/ WHITE combo.
If not, quickly DOUBLE CLICK the PAIR
button again.
4
STEP 4: Turn ON Bluetooth function
on your playback device, select "iHome
iHRK-500LTMS".
BLUETOOTH
OTHER DEVICES
iHome iHRK-500LTMS
5
STEP 5: Power ON the next speaker. If LED is WHITE, speaker is set as "LINK" and it's ready to play. If not,
SINGLE CLICK the PAIR button to assign as "LINK" speaker. If flashing BLUE, single press again. Speaker
will announce "Broadcast mode enabled" and LED should be flashing WHITE while the speakers at-
tempt to pair. Linking should occur automatically, once successfully linked the LED on 2nd speaker will
be FULLY LIT in WHITE. Master speaker will be fully lit in BLUE/WHITE.
2ND SPEAKER
MASTER
2ND SPEAKER
i
Repeat the above step to link additional speakers.
Please note: Your media device connects to the MASTER speaker and each subsequent LINK speaker connects to the MASTER. Be sure
to keep your audio device within range of MASTER SPEAKER (32 ft) and each LINK speaker within range of MASTER SPEAKER (32 ft.)
Play some audio. You should now hear
your audio playback out of the master
speaker.
"BLUETOOTH
CONNECTED"
"BROADCAST
MODE ENABLED"
FLASHING WHITE
MASTER 2ND SPEAKER
SOLID BLUE / WHITE SOLID WHITE
"BROADCAST
AUDIO ENABLED"
SUCCESSFULLY
PAIRED
