LEDMO XL-7 Manual

ntroduction
I
This LED lighting fixture is consisted of high power LEDs ,which is an environmental, energy-saving and the best solution of replacements
for conventional Lightings. Various white colors configurations are available, such as cool white, warm white, natural white color.
Features & Applications
(1) extended-aluminium housing, 4mm toughened glass,Ip65.
(2) As a decorative product, Could be widely used for sculptures, landmark buildings, stadiums,plazas, gardens, public parks and
so on, especially used in virescence, the wall of highrises, landscapes etc.
Technology Parameter
NO
Item
1 Operating voltage
2 Max power consumption
Beam angle
3
LED Color
4
5
Operating humidity
6
IP Rating
7 Life time
8 Projection distance
9 Weight
10
Max projected area
11 Mounting height
12 Dimension(mm )
3
Suitable for wet locations
Installation Instruction(Only by an approved electrician)
1.Get the expansion screws(M6x80mm)in the accessory bag, drill to install 2 units M6 stainless steel with 80MM between two holes
expansion screws in proper position or on ground.
2.Penetrate the corresponding holes of the fitting through screws, set the gasket, screw the nuts, and then fix the light.
3.Connect the lights in a sequence as per the signal connecting sketch map and take the waterproof measures.
4.Get the power supply connected, and debug the programme. Adjust the angle of elevation as requested.
5.Fragile glass, handle with care, The non-artficial damage of glass,can be replaced.
Maintenances
1.In order to the life time of the product and more safe operation, please keep it clean, maintenance and preserve.
2.While cleaning the lamp, please use the soft cloth with soap water and wring it, then try to sweep.
3.Don't use the volatile chemic liquid such as alcoholic, gasoline or pesticide to sweep, otherwise, easily damage the lamp, thereby affect the life time of it.
4.Fragile glass, handle with care, The non-artficial damage of glass,can be replaced.
Cautions
1.Make sure that the product is installed Before plug in.
2.Please notice that don't use any objectives to cover the lamp.
3.Don't use the lamp under sealed environment.
4.Maintenance should only be done by a professional technician.
5.In case of any change to the product we retain the right to inform you in advance.
6.If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer or his service agent or a similar
qualified person in order to avoid a hazard.
7.Terminal block to be used shall conform to EN 60998-2-1 or EN 60998-2-2; and shall be specified as following: - the type of terminal: screw/screwless;
- number of terminals: 3 poles; - rated voltage: Min. 240 V; - rated connecting capacity: Min. 1,0mm - any necessary preparation of the ends of conductors:
the length of exposed ends of conductors shall not more than 8 mm;- any fixing method: fixed inside the connecting box.
Notes:
Do not dispose of electrical appliances as unsorted municipal waste, Use separate collection facilities. Contact you local government
for Information regarding the collection systems available. If electrical appliances Are groundwater and get into the food chain,
damaging your health and well-being.
