If the video tray bracket is not securely mounted on the post in
Step 8, please follow the instructions:
1. Loosen the bolt [Z] and bolts [K] to remove the connecting plate cover,
and save the small iron plate on the slot of the cover for the next step. (Find
the small iron plate which may fall on the floor, if it is not on the slot.)
K
Z
2. Put the small iron plate on the slot, and thread the bolt [Z] through the
cover and into the small iron plate. Insert the video tray bracket, and ensure
the small iron plate fits into the groove on the bracket.
Z
Advertisement
Summary of Contents for Perlegear PGTVMC11
- Page 1 If the video tray bracket is not securely mounted on the post in Step 8, please follow the instructions: 1. Loosen the bolt [Z] and bolts [K] to remove the connecting plate cover, and save the small iron plate on the slot of the cover for the next step. (Find the small iron plate which may fall on the floor, if it is not on the slot.) 2.
- Page 2 3. Fully tighten the bolt [Z], and reattach the video tray bracket assembly to the post by tightening the bolts [K].
