TIPS:
◆ When grinding multiple Tungsten in a row, periodically let guide cool to
prevent melting the Angles Controller body.
◆ When grinding: Apply light pressure to wheel. Heavy pressure will
result in excessive wheel wear and a rougher Tungsten point.
INSTALLATION:
1) Unscrew top collar on Rotary Tool, and choose a correct size collet
for 1/8" mandrel.
1 / 2
Advertisement
Summary of Contents for 3mirrors B00601A
- Page 1 TIPS: ◆ When grinding multiple Tungsten in a row, periodically let guide cool to prevent melting the Angles Controller body. ◆ When grinding: Apply light pressure to wheel. Heavy pressure will result in excessive wheel wear and a rougher Tungsten point. INSTALLATION: 1) Unscrew top collar on Rotary Tool, and choose a correct size collet for 1/8”...
- Page 2 2) Install the Angle Controller as showed in Picture-1. 3) Connect the mandrel with Diamond wheel, and set it in your rotary tool. As Picture-2. 4) Adjust the height of the Diamond wheel. Screw the collet when you are sure the Below of the Long window is on the same PLANE as the top face of the Diamond wheel.
