If you loosed this two
bolts, inside springs and
the bracket of slider will
pop up together.
There is two location pillars
inside the bracket for
installing the springs, we
must place the spring on the
location pillar as right photo.
After the two springs were
installed to location pillars ,
then hold the springs and
insert them into the slots
on the slider as right photo.
Advertisement
Related Manuals for NEU MASTER NTC0040
Summary of Contents for NEU MASTER NTC0040
- Page 1 If you loosed this two bolts, inside springs and the bracket of slider will pop up together. There is two location pillars inside the bracket for installing the springs, we must place the spring on the location pillar as right photo. After the two springs were installed to location pillars , then hold the springs and...
- Page 2 Insert the two springs to the slot slowly and completely. then locked the slider as right photo. Tighten the bolt with wrength, the slider assembly done.
