- Page 1 4-IN-1 PIN-TYPE MOISTURE METER KC-315A USER’S MANUAL...
-
Page 3: Table Of Contents
The device utilizes low-power SCM intelligent design, and the measurement results are displayed on an LCD screen. In addition to measuring moisture content, the KC-315A also includes an environmental temperature and humidity measurement function. This feature allows users to quickly determine whether the current environmental conditions are conducive to mold growth. -
Page 4: Lcd Screen Overview
LCD SCREEN OVERVIEW A. Buzzer function identifier B. Pin mode identifier C. Battery indicator D. Moisture level display E. Mildew index gear display F. Moisture value display G.Locking sign H.Measurement mode: WOOD wood mode; BLDG building materials mode I.Ambient temperature value J.Temperature value unit K.Ambient humidity OPERATING INSTRUCTIONS... -
Page 5: Calibration Instruction
● Red indicator block ->20% ~33%:EXCESSIVE DAMPNESS. 3. Mildew index display: The mildew index is 9 levels in total, and the higher the index is, the easier the mildew will occur; CALIBRATION INSTRUCTION This instrument features an external calibration function for enhanced accuracy. To calibrate, remove the probe protection sleeve, power on the instrument, and insert the two probes into the two small holes located at the back of the protection sleeve while in wood mode. -
Page 6: Specifications
SPECIFICATIONS WOOD 5~50% BUILDING Measuring range 1.5~33% MATERIALS Moisture measurement accuracy ± 1.5% Temperature/humidity temperature -9.9~50℃ :± 1℃ (14~122℉: ± 1.8℉) measurement humidity 0~99.9%RH ± 3% No operation backlight darkening time About 15 seconds Automatic shutdown No operation for 2 minutes Power supply 2*AAA Maximum power consumption...
