Hubbell RACO 812C Instruction Sheet

INSTRU C T IO N SHE E T
A sse mb ling RACO
Cr us he d Corners Covers
STE P 1
Remove and retain the mounting screws included with the
device. These screws will be used to secure the device to
the cover. Retain nuts if they are provided.
STEP 3
Wire the device or devices per manufacturer instructions.
Note: If you do not see the perforation it might be necessary to
snip the pieces off with a cutting tool. Avoid removing too much
strap to maintain the integrity of the device mounting holes.
Rev. 11/09/22
RA_362 Instr -rev2
©
2022 Raco, a division of Hubbell Incorporated. All rights reserved. Specifications subject to change without notice.
3902 W Sample Street • South Bend, IN 46619 / Tel 574.234.7151 / www.hubbell.com/raco/en
ST EP 2
Prepare the device for mounting by removing the ears
from the mounting strap or yoke by bending back
and forth a few times at the performation. For most
receptacles also remove the ends of the strap at the
perforation.
ST EP 4
Secure the device to the cover using the device mounting
screws. On some devices the nuts provided with the cover
are required to secure the device to the cover.
Scan the QR code
to Watch the full
instruction video
