WESTBRASS Velosah D271-NL-12 Manual

WESTBRASS
Fine Decorative Plumbing Since 1935
Typical Installation
HotMaster
™
by WESTBRASS™
2429 E Olympic Blvd., Los Angeles, CA 90021
Ph. (213) 627-8441 www.westbrass.com info@westbrass.com
X
COLD
WATER
Cold Water Supply
1
Install Tee in Cold
water supply line
- not included
Or
Instal Dual Outlet
angle stop for
cold water supply.
Install the Faucet
2
Apply thin
2-1/2" Dia. - 1-3/8" Hole
Maximum Deck
1/4" Tubing Thickness - 2-3/4"
bead of sili-
Cold Water Inlet to Hot Water
Directly Under Hot Handle
cone around
1/4" Tubing
Outlet to tank (Red)
the o-ring at
Hot Water Hose
1/4" Tubing
the base of
Inlet to Cold Water
Under Cold Handle
the faucet
2-1/2" Dia. - 1-3/8" Hole
Mount using
Maximum Deck
1/4" Tubing
Thickness - 2-3/4"
Nut, Waser
Cold Water Inlet (Blue)
Directly Under Hot Handle
and Spacer
1/4" Tubing
Outlet to tank (Red)
below sink
