- Page 1 FRONT FENDER FLARES User Manual 2019-2022 Wrangler JT Model: NJT01H101-F Material: Q235A Product Dimensions: 44.3 x 12.4 x 19.8 inch Package Dimensions: 56.3 x 21.7 x 13.4 inch Product Weight: 45.64 lbs...
- Page 2 ※ Thank you for purchasing the FENDERS FLARES. Please read this manual carefully and keep it properly if you need to refer to it afterward. If you need any support or assistance, please contact us with your product model number and order number, and our support team will help you solve problems.
-
Page 3: Required Tools
REQUIRED TOOLS Socket Ratchet Allen Wrench Safety Glasses Parts Information Parts NO. Parts Name Size Line Graph Color Front Fender Black Flares Half Head Allen M8x20 Dacro Black Bolts Flat Washer Φ8x24x2mm Dacro Black Hex Flange Dacro Black Nuts Nylon Washer Φ8x16x0.5 Black Ribbon... -
Page 4: Installation Instructions
Installation Instructions Step 1: Open the carton and take out the parts. Check whether the number of components is complete. Step 2: Remove the original front fender flares and original front inner fender flares and prepare the parts needed to install the Front Inner Fender Flares. Step 3: Install the front fender flares and tighten the bolts. - Page 5 Step 4: Connect the front fender flares light wiring. Fender flares wiring Fender flares wiring Fender flares wiring...
- Page 6 Car wiring Fender flares wiring Fender flares wiring Step5: Bundling wires. Step 6: Installation of a front fender flares is complete. Please do periodic inspections of the fender flares to make sure that all hardware is secure and tight. Step 7: Install the original front fender flares.
