Drok B0BDLCR913 Manual

200600
DROK 24V Stepper Motor Driver
Working Voltage DC 5-30V
Rated Current
12A
Maximum Current 20A
Maximum Power
360W
Working Frequency 1KHz-99KHz
PWM Duty Ratio 00.0-100 Adjustable
Pre-charge Time
0.0-9.9 seconds
Pre-stop Time 0.0-9.9 seconds
Stepper Value 0.1-25
Product Size 79*43*26mm / 3.11*1.69*1.02inch
Install Size
76.5mm*39.3mm / 3.01*1.55inch
42g
Weight
The parameters will be saved after power off.
Setting Instruction
Long Press the knob for 8 seconds to enter setting interface,
short press to switch, rotate to adjust the parameter value,
long press for 2 seconds to save and exit.
PON: Default output when power on
POF: Default output close when power on
L00-L49: Lowest output set to 00%- 49%
H100-H50: Highest output set to 100%-50%
F01-F99: PWM frequency set to 1Khz-99Khz
O0.0-O9.9: Reach to 100% speed from 0.0-9.9
seconds
C0.0-C9.9: Stop to 0% speed from 0.0-9.9
seconds
Size
79mm/3.1in
Recommend product
Visit DROK Store
on Amazon:
on Amazon
12V 24V Motor Driver
26mm/1.03in
