PartNo Revision DESCRIPTION
1 181941-C C SHUT-OFF, SM II ONLY
2 181822-A A ADJUSTABLE NOZZLE, POLY, SM II
3 181804-a A CAP NUT, NOZZLE, SM II
4 181812-A A FLAT SEAL, NOZZLE, VITON
5 181824-B B WAND ASSEMBLY, 21", PP, SM II
6 181968-A A BOARD ROUNDUP SMII, CARDED PARTS
7 173130-A A SHRINK WRAP, CARDED PARTS, BP
8 182009-A A CARTON, OVP, INNER, 6 PER, 4.43 x 2
9 182010-A A CARTON,OUTER, 6 PER, 4.43 x 2
NOTE: PLACE COMPONENTS AS SHOWN
AND SHRINK WRAP INTO PLACE.
B ADDED 182009 & 182010 OVERPACK CARTONS
A RELEASE TO PRODUCTION
REV. DESCRIPTION
REVISIONS
MATERIAL:
The
As Noted on Drawing Fountainhead
Group, Inc.
TITLE:
KIT, SMII S/O WAND & NOZZLE, ROUNDUP
