- Page 1 Robotic Lawn Mower Shade SKU: LF-RLS1 Instruction Manual...
- Page 2 CAUTION! If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@life-finds.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Package Contents
Package Contents A (x1) B (x2) C1 (x1) Shade Frame Front Shade Support C2 (x1) D (x2) Rear Shade Support Included Hardware & Tools S-A (x4) S-B (x2) S-C (x2) S-D (x4) S-E (x4) ST4x24mm M10x35mm M10x25mm M10 Washer M10 Nut Screws Screws Screws... -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Remove the protective film on Shade (A), Front Shade Support (C1), and Rear Shade Support (C2). Install the Slide Shade Supports onto the short ends of Shade. Round Side Edges Square Side Edges Front Shade Support (C1) Rear Shade Support (C2) - Page 5 STEP 2 Slide Frame pieces (B) on to the side of Shade (A).
- Page 6 STEP 3 Secure Frame Pieces (B) into Shade Support (C) using ST4x24mm Screws (S-A) and a Phillips screwdriver. S-A (x4)
- Page 7 STEP 4 Secure Feet (D) to Supports (B) using M10x35mm Screws (S-B), M10 Washers (S-C), and M10 Nuts (S-E) in the back upper holes. Use M10x25mm Screws (S-C), Washers, and Nuts in the back lower holes. Tighten both sets using an adjustable wrench. Use Ground Stakes (W-A) and a hammer to secure assembled shade to desired location in yard.
- Page 8 LAST UPDATED: 01/31/2024 REV1.1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com 309-278-5303...
