Okayo EJ-601TM Operating Instructions

operating instructions :
2.4G wireless digital handheld microphone
1.mesh grille
2.Handheld tube
3.Power indicator
4.On/Off button
5.LCD display shows channel, battery meter 11.(Charging contacts
6.UP/DOWN/SET wheel
2.4G wireless digital handheld microphone setup
1.Remove batteries, set Master/Slave switch (10) to a desired position.
※When Mic is set to Master, ch A will be a designated channel.If ch A is unavailable, it will change to
ch B as a result.
※When Mic is set to Slave, ch B is the designated channel, which will be displayed in screen.
2.Set Mute/Talk, Push/Talk through software.
※Press and hold SET button then turn on handheld microphone to enter setup mode. The screen will
flash "MT" or "PT" for option through UP or DOWN .
3.Press and hold power button for about 1 second to power on. Then power indicator (3) will illuminate.
※Blue power indicator stands for enough battery power; red indicator stands for low battery.
4.Channel synchronization
1. Synchronization will be made once when the unit is turned on.
2. When synchronization is made successfully, channel number will be displayed in
button will light blue. If synchronization is failed, LCD screen will show battery meter and blank
channel number, mute button will light red.
※Synchronization works in the range of 15 meter.
EJ-601TM
7.Mute/Talk switch
8.Battery compartment
9.Battery door)
10.Master/Slave switch
LCD and mute
